35 SCREW-BRACKET FAN MOTOR 4 CWH551040
36 FAN MOTOR 2 CWA951077
CWA951078
37 FAN MOTOR SUPPORTER 2 -
CWD932142
38 SCREW-FAN MOTOR 8 CWH55442
39 PROPELLER FAN 2 CWH001007
40 WASHER for P.FAN 2 CWH571013
41 SPRING WASHER for P.FAN 2 XWB10B
42 NUT for PROPELLER FAN 2 CWH56033
43 P.FAN AIR GUIDER PLATE 1 CWE061042A
CWE061044A
44 FAN GUARD 2 CWD041014A
45 CONDENSER GUARD 1 CWD041016A
CWD041017A
46 CABINET TOP PLATE COMPLETE 1 CWE03C1004
CWE03C1005
47 FLARE NUT (3/8”) 1 CWT25005
48 FLARE NUT (6/8”) 1 CWT251012
49 PIPE COVER (FRONT) 1 CWD601017A
50 PIPE COVER (BACK) 1 CWD601018A
51 CABINET FRONT PLATE 1 CWE061046A
52 HANDLE 3 CWE161008
53 HANDLE 1 CWE161009
54 LEADWIRE-COMPRESSOR 1 CWA67C3876 CWA67C3656
55 ACCESSORY COMPLETE 1 CWH82C1105
INSTALLATION INSTRUCTION 1 CWF612231
All parts are supplied from MACC, Malaysia (Vendor Code: 086)
NO. PART DESCRIPTION QTY. CU-C34BBP5 CU-C34BBP8 CU-C43BBP8 CU-C50BBP8
1 BASE PAN ASS’Y 1 CWD52K1039A
CWD52K1040A
2 COMPRESSOR 1 ZR47K3PFJ522 ZR45KCTFD522 ZR57KCTFD599 ZR68KCTFD599
3 ANTI-VIBRATION BUSHING 4 CWH501020
4 NUT FOR COMP. MOUNT. 3 CW4582065
5 CRANKCASE HEATER 1 CWA341004
CWA341002
6 CONDENSER COMPLETE 1 CWB32C1093
CWB32C1097
7 TUBE ASS’Y (CAPILLARY TUBE) 1 CWT07K1025
CWT07K1021
8 PIPE HOLDER RUBBER 1 CWG251016
CWG251021
8 PIPE HOLDER RUBBER 1 CWG251015
9 CONDENSER SIDE PLATE 1 CWD911123
10 CONDENSER TOP PLATE 1 CWD911132
CWD911133
11 TUBE ASS’Y (PRESSURE SW+RCVR) 1 CWT022366
CWT022377
12 HIGH PRESSURE SWITCH 1 CWA101002
13 ACCUMULATOR 1 CWB131009A
CWB131011A CWB131012A
14 TUBE ASS’Y (3 WAY VALVE-GAS) 1 CWT022365
CWT022367 CWT022368
15 TUBE ASS’Y(VALVE+STRAINER) 1 CWT022359
CWT022360 CWT022361
