MODEL / ITEM
CS-A34BD3P/CU-A34BBP8
Condition by JIS B 8616
Volts V 380 400 415
Phase 3N 3N 3N
Input Power kW Cool 3.65 3.65 3.65
Heat 3.40 3.40 3.40
Running Current A Cool 6.5 6.5 6.5
Heat 5.8 5.8 5.8
Starting Current A 39 41 42
Power Factor % Cool 85 81 78
Heat 89 85 82
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power
source
AC, 3N~380V, 400V, 415V 50Hz
3.6 CS-A43BD3P / CU-A43BBP8
ITEM / MODEL
Indoor Unit Outdoor unit
Main Body CS-A43BD3P CU-A43BBP8
Cooling Capacity kW 13.00
(BTU/h) (44,300)
Heating Capacity kW 14.20
(BTU/h) (48,400)
Refrigerant Charge-less m 30
Standard Air Volume for High
Medium and Low Speed
m
3
/min
Hi 40 Hi 82
cfm Hi 1413 2895
External Static Pressure mmAq Hi 5 Me 4 Lo 3 -
Pa Hi 49 Me 39 Lo 29
Air Inlet Backward Suction Rear sided
Air Outlet Front blow-out Front blow-
Outside Dimension (H x W x D) mm 270 x (1500 + 100) x 650 1220 x 1100 x
Net Weight kg (lbs) 55 (121) 114 (251)
Piping
Connection
Refrigerant
Gas mm (inch) O.D Ø 19.05 (3/4) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain mm Female screw RC1 (PT1) I.DØ 20 x 1
Compressor
Type, Number of Set - Hermetic-1 (
Starting Method - Direct on-line
Motor Type - 2-pole 3 phase
motor
Input kW - Cool/Heat 3.85/
Rated
Output
kW - 3.54
