Panasonic CS-A24BD3P

ITEM / MODEL
Indoor Unit Outdoor
unit
Main Body CS-A28BD3P CU-
C28BBP8
Cooling Capacity kW 7.30
(BTU/h) (24,900)
Refrigerant Charge-less m 30
Standard Air Volume for High
m
3
/min
Hi 25 Hi 43
Medium and Low Speed cfm Hi 883 1518
External Static Pressure mmAq Hi 5 Me 4 Lo 3 -
Pa Hi 49 Me 39 Lo 29
Air Inlet Backward Suction Rear sided
Suction
Air Outlet Front blow-out Front blow-
out
Outside Dimension (H x W x D) mm 270 x (1000 + 100) x 650 900 x 900 x
320
Net Weight kg (lbs) 40 (88) 82 (181)
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain mm Female screw RC1 (PT1) I.DØ 20 x 1
Compressor
Type, Number of Set - Hermetic-1 (
Rotary),
Starting
Method
- Direct on-line
starting
Motor Type - 2-pole single
phase
induction
motor
Input kW - Cool/2.49
Rated
Output
kW - 2.0
Fan Type, Number of Set Sirocco fan-2 Prop. fan-1
Air Volume Control Three-Step and Auto mode -
(Remote Control)
Motor Type 4-pole single phase
induction motor
6-pole single
phase
induction
motor
Input kW 0.19 0.11
Rated
Output
kW 0.115 0.05
Air-heat exchanger Louvre-fin type Louvre-fin
type
Refrigerant Control Capillary tube Capillary
tube
Refrigerant oil (Charged) L - MS32 (1.3)
Refrigerant (Charged) kg (oz) - R-22 3.8 (
134)
Running
Adjustment
Control Switch Wired Remote Control -
Room Temperature Thermostat (Main Body) -
Safety Devices Heat Thermostat for compressor, Internal
thermostat
F.M, Crankcase heater, High pressure switch,
Current
Transformer
Noise Level dB (A) Hi 42 Lo 38 Hi 50
1. Cooling capacities are based on indoor temp. 27°C D.B. (80.6°F
D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air temp. 35°C D.B.
