Models (Cooling Only
Model)
CS-A24BD3P CS-A28BD3P CS-A34BD3P CS-A43BD3P CS-
Tube Material Copper Tube
Outer
Diameter
mm 9.53 9.53 9.53 9.53
Thickness mm 0.28 0.28 0.3 0.28
Row 3 3 2 3
No. of Tubes/
Row
10 10 10 10
Fin Material Aluminium
Thickness mm 0.11 0.11 0.11 0.11
Fin Pitch No./
inch
14 14 14 12
Fin Surface Louvre-fin Louvre-fin Louvre-fin Louvre-fin
Total Face
Area
G 0.218 0.218 0.345 0.345
Evaporator Fan Sirocco Fan
Type
No./Unit 2 2 2 2
Evaporator Fan
motor
Direct On-Line Starting
Starting
Rated Output kW 0.085 0.115 0.15 0.26
Poles 4 4 4 4
Phase Single-Phase Single-Phase Single-Phase Single-Phase
Insulation E E E E
15. CAPACITY AND POWER CONSUMPTION
15.1. COOLING CAPACITY CURVE, COOLING POWER
CONSUMPTION CURVE
COOLING CAPACITY CURVE
