Model
CS-A24BD3P/CU-A24BBP5, CS-C24BD3P/CU-C24BBP5
COOLING PERFORMANCE
Ambient Temperature Air Entering Condenser (°C D.B.)
Return 25°C 30°C 35°C 40°C 45°C
Air TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT TC SHC
D.B. W.B. kW kW kW kW kW kW kW kW kW kW kW kW kW kW
17 6.84 5.98 2.09 6.58 5.88 2.25 6.25 5.76 2.39 5.86 5.51 2.55 5.40 5.07
23 19 7.17 5.19 2.25 6.91 5.13 2.39 6.58 5.01 2.55 6.25 4.88 2.71 5.86 4.68
22 7.76 4.02 2.49 7.50 4.02 2.62 7.17 3.98 2.78 6.84 3.93 2.91 6.44 3.82
17 6.80 5.95 2.09 6.54 5.84 2.25 6.21 5.72 2.39 5.82 5.47 2.55 5.36 5.04
25 19 7.12 5.16 2.25 6.86 5.10 2.39 6.54 4.98 2.55 6.21 4.85 2.71 5.82 4.65
22 7.72 3.99 2.49 7.46 4.00 2.62 7.12 3.95 2.78 6.80 3.90 2.91 6.41 3.80
17 6.76 5.91 2.09 6.50 5.81 2.25 6.18 5.69 2.39 5.79 5.44 2.55 5.33 5.01
27 19 7.09 5.13 2.25 6.83 5.07 2.39 6.50 4.95 2.55 6.18 4.82 2.71 5.79 4.63
22 7.67 3.96 2.49 7.41 3.97 2.62 7.09 3.93 2.78 6.76 3.88 2.91 6.37 3.77
17 6.72 5.88 2.09 6.46 5.78 2.25 6.15 5.66 2.39 5.76 5.41 2.55 5.30 4.98
29 19 7.05 5.10 2.25 6.79 5.05 2.39 6.46 4.92 2.55 6.15 4.79 2.71 5.76 4.60
22 7.63 3.95 2.49 7.37 3.95 2.62 7.05 3.91 2.78 6.72 3.86 2.91 6.33 3.75
17 6.67 5.83 2.09 6.42 5.73 2.25 6.09 5.61 2.39 5.71 5.37 2.55 5.26 4.94
32 19 6.99 5.06 2.25 6.73 5.00 2.39 6.42 4.89 2.55 6.09 4.76 2.71 5.71 4.57
22 7.57 3.91 2.49 7.32 3.92 2.62 6.99 3.88 2.78 6.67 3.82 2.91 6.29 3.73
Legend : BF Bypass Factor 0.20 SHC Sensible Heat Capacity TC Total Cooling Capacity /
CAPACITY SELECTION NOTES / (1) The table above is based on unit nominal evaporator
airflow, / correction factor must therefore be applied for selections / away from this condition. /
COOLING CORRECTION FACTORS
EVAP. AIR FLOW m
3
/
min (l/s)
14 (233) 17 (283) 20 (333) 23 (383)
SHC Sensible Heat
Capacity
0.86 0.93 1 1.08
TC Total Cooling
Capacity
0.92 0.96 1 1.05
