Panasonic CS-A28BB4P Service Manual

Heat
Hi
45
Me
42
Lo
40
Hi
56
1. Cooling capacities are based on indoor temperature of 27°C D.B.
(80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature of 20°C D.B.
(68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F D.B.),
6°C W.B. (42.8°F W.B.)
ELECTRICAL DATA (50Hz)
ITEM / MODEL
CS-A34BB4P, CU-A34BBP5
Condition by JIS B 8615
Volts V 220 230
240
Phase Single Single
Single
Power Consumption kW Cool 3.60 3.60
3.60
Heat 3.55 3.55
3.55
Running Current A Cool 17.0 17.1
17.2
Heat 16.8 16.9
17.0
Starting Current A 94 99
103
Power Factor % Cool 96 92 87
Heat 96 91 87
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 1~220V, 230V, 240V
50Hz
3.5. CS-A34BB4P / CU-A34BBP8
ITEM / MODEL
Indoor Unit Outdoor
unit
Main Body CS-A34BB4P CU-
A34BBP8
Panel CZ-BT01P
Remote CZ-RD51P (Wired)
Control CZ-RL51P (Wireless)
Cooling Capacity kW 10.0
BTU/h 34,100
Heating Capacity kW 11
BTU/h 38,200
Refrigerant Charge-less m 30
Standard Air Volume for High,
m
3
/min
Hi 26 Me 23 Lo 20 Hi 70
Medium and Low Speed cfm 918 812 706 2471
Outside Dimension (H x W x D) mm 290 x 840 x 840 1220 x 900
x
inch 11-7/16 x 33-1/24 x 33-1/24 48-1/24 x 35-7/16
x
Net Weight kg 30 97
lbs 66 214
17

Panasonic CS-A28BB4P Specifications

General

Brand	Panasonic
Model	CS-A28BB4P
Category	Air Conditioner
Language	English
