Panasonic CS-A28BB4P Service Manual

ITEM / MODEL
Indoor Unit Outdoor
unit
Main Body CS-A24BB4P CU-
C24BBP5
Panel CZ-BT01P
Remote CZ-RD51P (Wired)
Control CZ-RL01P (Wireless)
Cooling Capacity kW 6.3
BTU/h 21,500
Refrigerant Charge-less m 30
Standard Air Volume for High,
m
3
/min
Hi 17 Me 15 Lo 14 Hi 43
Medium and Low Speed cfm 600 530 494 1518
Outside Dimension (H x W x D) mm 240 x 840 x 840 900 x 900
x
inch 9-7/16 x 33-1/24 x 33-1/24 35-7/16 x 35-7/16
x
Net Weight kg 26 80
lbs 57 176
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 6.35 (1/4) Flared Type
Drain mm O.D Ø 20 I.D Ø 20
x
Compressor
Type, Number of Set - Hermetic-1 (
Rotary),
Starting Method - Direct on-line
starting
Motor Type - 2-pole single
phase
induction
motor
Input kW - Cool
2.31
Rated
Output
kW - 1.9
Fan Type, Number of Set Turbo fan-1 Propeller
fan
Motor Type 4-pole single phase
induction motor
6-pole single
phase
induction
motor
Input kW 0.08 0.11
Rated
Output
kW 0.03 0.05
Air-heat Exchanger Slit-fin type Louvre-fin
type
Refrigerant Control Capillary tube -
Refrigerant Oil (Charged) litre - MS32 (
1.3)
Refrigerant (Charged) kg
-
(2.5)
lbs (11.1)
Running
Adjustment
Control Switch Wireless or Wired Remote
Control
-
Room Temperature Thermostat (Main Body) -
Safety Devices Internal protector for compressor, Internal
thermostat
fan motor, Crankcase heater, High pressure
switch,
Current transformer
Noise Level dB Hi 42 Me 40 Lo 38 Hi 50
1. Cooling capacities are based on indoor temperature of 27°C D.B.
(80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
23

Panasonic CS-A28BB4P Specifications

General

Brand	Panasonic
Model	CS-A28BB4P
Category	Air Conditioner
Language	English
