Panasonic CS-A28BB4P Service Manual

Models CS-A24BB4P CS-A28BB4P CS-A34BB4P CS-A43BB4P
A50BB4P
Tube Material Copper tube
Outer Diameter mm 7.0 7.0 7.0 7.0
Thickness mm 0.27 0.27 0.27 0.27
Row 2 2 2 3
No. of Tubes/Row 8 8 12 12
Fin Material Aluminium
Thickness mm 0.105 0.105 0.105 0.105
Fin Pitch NO./
inch
17 17 19 19
Fin Surface Z Slit fin Z Slit fin Z Slit fin Z Slit fin
Z
Total Face Area
m
2
0.304 0.304 0.456 0.464
Fan Type Turbo fan
No. of /Unit 1 1 1 1
Fan
Motor
Starting Method Direct on-line
Starting
Rated Output kW 0.03 0.03 0.05 0.095
Poles 6 6 6 6
Phase Single-Phase Single-Phase Single-Phase Single-Phase
Single
Insulation Class E E E E
Condenser
Models Heat
pump
CU-
A24BBP5
CU-
A28BBP5
CU-
A34BBP5
CU-
A43BBP8
A50BBP8
model CU-
A28BBP8
CU-
A34BBP8
Cooling
only
model
CU-
C24BBP5
CU-
C28BBP5
CU-
C34BBP5
CU-
C34BBP7
CU-
C43BBP8
C50BBP8
CU-
C28BBP8
CU-
C34BBP8
CU-
C43BBP7
C50BBP7
CU-
C28BBP6
80
