17.2.2. Replacement Parts List (Indoor Unit)
Models:
CS-ME10DD3EG / CS-E15DD3EW / CS-E18DD3EW
REF NO. PART NAME & DESCRIPTION QTY. CS-ME10DD3EG CS-E15DD3EW CS-E18DD3EW REMARKS
1 FLOAT SWITCH 1 CWA12161 ←
←←
← ←
←←
←
2 THERMAL FUSE 1 CWA16C1038 ←
←←
← ←
←←
←
3 TERMINAL BOARD COMPLETE 1 CWA28K1045J ←
←←
← ←
←←
←
6 SENSOR COMPLETE 1 CWA50C2270
←
←←
← ←
←←
←
9 REMOTE CONTROL (RECEIVER) 1 CWA75C2773 ←
←←
← ←
←←
←
10 REMOTE CONTROL 1 CWA75C2610X ←
←←
← ←
←←
←
11 FAN MOTOR 1 ARW41G8P30AC
←
←←
← ←
←←
←
12 EVAPORATOR 1 CWB302123XA CWB302123XB CWB302356X
13 DRAIN PUMP COMPLETE 1 CWB53C1010 ←
←←
← ←
←←
←
14 PARTICULAR PLATE-1 1 CWD11024XA ←
←←
← CWD11026XA
15 AIR GUIDER-1 2 CWD32091
←
←←
← ←
←←
←
16 AIR GUIDER-2 2 CWD32092 ←
←←
← ←
←←
←
17 BOTTOM PLATE 1 CWD52259X ←
←←
← ←
←←
←
18 BULKHEAD 1 CWD531019 ←
←←
← ←
←←
←
19 BRACKET FAN MOTOR 1 CWD541036 ←
←←
← ←
←←
←
20 PARTICULER PLATE-2 1 CWD74100 ←
←←
← ←
←←
←
22 HOLDER LEAD WIRE-1 1 CWH31103 ←
←←
← ←
←←
←
23 PARTICULER PLATE-3 1 CWD90K080 ←
←←
← CWD90K086
24 PARTICULER PLATE-4 1 CWD90616 ←
←←
← CWD90635
25 PARTICULER PLATE-5 1 CWD90618 ←
←←
← ←
←←
←
26 PARTICULER PLATE-6 1 CWD90766 ←
←←
← ←
←←
←
27 CABINET BACK PLATE 1 CWE02079
←
←←
← ←
←←
←
28 CABINET TOP PLATE-1 1 CWE03034 ←
←←
← ←
←←
←
29 CABINET TOP PLATE-2 2 CWE03035X
←
←←
← ←
←←
←
30 CABINET SIDE PLATE-1 1 CWE04071 ←
←←
← CWE04079
31 CABINET SIDE PLATE-2 1 CWE04072X ←
←←
← CWE04080X
42 INSULATION SHEET-1 1 CWG07165 ←
←←
← CWG07174
43 INSULATION SHEET-2 1 CWG07166 ←
←←
← CWG07175
44 INSULATION SHEET-3 1 CWG07167 ←
←←
← CWG07176
45 CROSS-FLOW FAN COMPLETE 1 CWH01C005 ←
←←
← ←
←←
←
47 CONTROL BOARD BOX 1 CWH10527 ←
←←
← ←
←←
←
48 CONTROL COVER 1 CWH131144X ←
←←
← ←
←←
←
49 HOLDER LEAD WIRE-2 1 CWH31044 ←
←←
← ←
←←
←
50 HOLDER LEAD WIRE-3 1 CWH31030
←
←←
← ←
←←
←
51 HOLDER LEAD WIRE-4 1 CWD77013
←
←←
← ←
←←
←
53 DRAIN TRAY 1 CWH40C061 ←
←←
← ←
←←
←
54 BELT 1 CWH4605008 ←
←←
← ←
←←
←
55 BUSHING-1 2 CWH4610440 ←
←←
← ←
←←
←
56 CAP-1 (1/4" LIQUID SIDE) 1 CWH52061 ←
←←
← ←
←←
←
59 BUSHING-2 1 CWH50147 ←
←←
← ←
←←
←
60 BUSHING-3 1 CWH50146
←
←←
← ←
←←
←
61 BUSHING-4 1 CWH51134
←
←←
← ←
←←
←
62 CAP-2 (GAS SIDE) 1 CWH52062 (3/8") CWH52063 (1/2")
←
←←
←
64 FULCRUM 1 CWH64C015
←
←←
← ←
←←
←
65 GUIDER-1 1 CWH691004
←
←←
← ←
←←
←
66 GUIDER-2 1 CWH69025 ←
←←
← ←
←←
←
67 FLARE NUT (1/4") 1 CWT25086
←
←←
← ←
←←
←
68 DRAIN HOSE COMPLETE 1 CWH85C008 ←
←←
← ←
←←
←
71 FLARE NUT (GAS SIDE) 1 CWT25087 (3/8") CWT25096 (1/2")
←
←←
←
81 COVER FOR RECEIVER 1 CWD66132B
←
←←
← ←
←←
←
82 RECEIVER PIECE-1 1 CWD90650
←
←←
← ←
←←
←
83 PARTICULER PIECE-1 2 CWD93435
←
←←
← ←
←←
←
85 PARTICULER PIECE-2 2 CWD93436
←
←←
← ←
←←
←
86 CABINET BOTTOM PLATE 1 CWE05012X ←
←←
← ←
←←
←
87 HOLDER SENSOR-2 1 CWH32137
←
←←
← ←
←←
←
88 PC BOARD (MAIN) 1 CWA73C1840 CWA73C1841 CWA73C1842
89 TRASFORMER (ON-BOARD) 1 CWA40C1027
←
←←
← ←
←←
←
90 FUSE (250V 3.15A) 1 XBA2C31TRO
←
←←
← ←
←←
←
91 ZNR 1 ERZVEAV511
←
←←
← ←
←←
←
92 BAG COMPLETE-1 (SCREWS, HOLDER) 1 CWG86C994
←
←←
← ←
←←
←
93 BAG COMPLETE-2 (SCREWS, BELT, ETC.) 1 CWH82C1277
←
←←
← ←
←←
←
(Note)
•
• •
•
All parts are supplied from ACD in Japan.
•
• •
•
“
” marked parts are recommended to be kept in stock.
