(NOTE)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
REF. NO. PART NAME & DESCRIPTION QTY. CU-E9FKR CU-E12FKR
1 CHASSY ASSY 1 CWD50K2073 ←
2 ANTI-VIBRATION BUSHING 3 CWH50077 ←
3 COMPRESSOR 1 5RS102XBC01 ←
4 NUT-COMPRESSOR MOUNT 3 CWH56000J ←
5 SOUND PROOF MATERIAL 1 CWG302293 ←
6 FAN MOTOR BRACKET 1 CWD541030 ←
7 FAN MOTOR(AC 25W SINGLE)(AC 30W SINGLE) 1 CWA951405J CWA951407J
8 SCREW - FAN MOTOR BRACKET 2 CWH551198 ←
9 SCREW - FAN MOTOR MOUNT 4 CWH55252J ←
10 PROPELLER FAN ASSY 1 CWH03K1006 ←
11 NUT - PROPELLER FAN 1 CWH56053J ←
12 CONDENSER 1 CWB32C1146 ←
13 TUBE ASS’Y CO (CAP./CHK VALVE) 1 CWT01C3257 CWT01C3258
14 HOLDER-COUPLING 1 CWH351023 ←
15 3 WAYS VALVE(GAS) 1 CWB011374 CWB011367
16 4 WAYS VALVE 1 CWB001037J ←
17 SOUND PROOF MATERIAL 1 CWG302292 ←
18 2-WAYS VALVE(LIQUID) 1 CWB021301 ←
19 DRYER 1 CWB101017J ←
20 V-COIL COMPLETE 1 CWA43C2143J ←
21 REACTOR 1 CWA421050 G0A193M00001
22 SENSOR COMPLETE 1 CWA50C2391 ←
23 CONTROL BOARD 1 CWH102273 ←
24 TERMINAL BOARD ASSY 1 CWA28K1110J ←
25 FUSE HOLDERS 1 K3GB1PH00016 ←
26 FUSES CAP TERMINAL 1 K5D203BBA002 ←
27 CONTROL BOARD 1 CWH102114 ←
28 CONTROL BOARD 1 CWH102115 ←
29 ELECTRONIC CONTROLLER-MAIN 1 CWA73C2401R CWA73C2402R
30 CONTROL BOARD COVER 1 CWH131104 ←
31 SENSOR COMPLETE 1 CWA50C2066 CWA50C2205
32 HOLDER SENSOR 1 CWH321010 ←
33 TERMINAL COVER 1 CWH171039A ←
34 NUT-TERMINAL COVER 1 CWH7080300J ←
35 CABINET SIDE PLATE CO. 1 CWE04C1011 ←
36 CABINET SIDE PLATE (LEFT) 1 CWE041031A ←
37 HANDLE 1 CWE161010 ←
38 WIRE NET 1 CWD041054A ←
39 CABINET FRONT PLATE CO. 1 CWE06C1039
←
40 CABINET TOP PLATE 1 CWE031014A ←
41 CONTROL BOARD COVER 1 CWH131110 ←
42 CONTROL BOARD COVER 1 CWH13C1064 ←
43 L-TUBE 1 CWH5850080 ←
44 PACKING-L.TUBE 1 CWB81012 ←
45 SOUND PROOF BOARD 1 CWH151025 ←
46 OPERATING INSTRUCTION 1 CWF565371 ←
47 INSTALLATION INSTRUCTION 1 CWF613024 ←
