Panasonic CS-E15NKR Service Manual

15
Type Cross-Flow Fan
Material ASG20K1
Motor Type Transistor (8-poles)
Input Power W 94.8 - 94.8
Output Power W 40
Cool rpm 640
QLo
Heat rpm 790
Cool rpm 830
Lo
Heat rpm 900
Cool rpm 1090
Me
Heat rpm 1130
Cool rpm 1350
Hi
Heat rpm 1370
Cool rpm 1370
Indoor Fan
Speed
SHi
Heat rpm 1370
Type Propeller Fan
Material PP
Motor Type Induction (6-poles)
Input Power W -
Output Power W 40
Outdoor Fan
Speed Hi rpm 530 - 550
Moisture Removal L/h (Pt/h) 2.4 (5.1)
Cool m
3
/min (ft
3
/min) 5.69 (201)
QLo
Heat m
3
/min (ft
3
/min) 7.49 (264)
Cool m
3
/min (ft
3
/min) 7.78 (275)
Lo
Heat m
3
/min (ft
3
/min) 8.72 (308)
Cool m
3
/min (ft
3
/min) 10.64 (376)
Me
Heat m
3
/min (ft
3
/min) 11.30 (399)
Cool m
3
/min (ft
3
/min) 13.5 (475)
Hi
Heat m
3
/min (ft
3
/min) 14.0 (495)
Cool m
3
/min (ft
3
/min) 13.96 (493)
Indoor
Airflow
SHi
Heat m
3
/min (ft
3
/min) 14.00 (495)
Cool m
3
/min (ft
3
/min) 40.3 (1425) 41.9 (1480)
Outdoor
Airflow
Hi
Heat m
3
/min (ft
3
/min) 40.3 (1425) 41.9 (1480)
Control Device Expansion Valve
Refrigerant Oil cm
3
FV50S (450)
Refrigeration
Cycle
Refrigerant Type g (oz) R410A, 1.12k (39.5)
Height(I/D / O/D) mm (inch) 290 (11-7/16) / 795 (31-5/16)
Width (I/D / O/D) mm (inch) 870 (34-9/32) / 875 (34-15/32)
Dimension
Depth (I/D / O/D) mm (inch) 214 (8-7/16) / 320 (12-5/8)
Weight Net (I/D / O/D) kg (lb) 9 (20) / 51 (112)
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 12.70 (1/2)
Standard length m (ft) 7.5 (24.6)
Length range (min – max) m (ft) 3 (9.8) ~ 15 (49.2)
I/D & O/D Height different m (ft) 15 (49.2)
Additional Gas Amount g/m (oz/ft) 20 (0.2)
Piping
Length for Additional Gas m (ft) 7.5 (24.6)
