Panasonic CS-E15NKR Service Manual

21
Type Cross-Flow Fan
Material ASG30K1
Motor Type Transistor (8-poles)
Input Power W 94.8 - 94.8
Output Power W 40
Cool rpm 860
QLo
Heat rpm 910
Cool rpm 960
Lo
Heat rpm 1000
Cool rpm 1150
Me
Heat rpm 1190
Cool rpm 1350
Hi
Heat rpm 1390
Cool rpm 1400
Indoor Fan
Speed
SHi
Heat rpm 1490
Type Propeller Fan
Material PP
Motor Type Induction (6-poles)
Input Power W -
Output Power W 80
Outdoor Fan
Speed Hi rpm 690 - 720
Moisture Removal L/h (Pt/h) 3.5 (7.4)
Cool m
3
/min (ft
3
/min) 10.07 (356)
QLo
Heat m
3
/min (ft
3
/min) 10.11 (357)
Cool m
3
/min (ft
3
/min) 11.46 (405)
Lo
Heat m
3
/min (ft
3
/min) 11.29 (399)
Cool m
3
/min (ft
3
/min) 14.11 (498)
Me
Heat m
3
/min (ft
3
/min) 13.78 (487)
Cool m
3
/min (ft
3
/min) 16.9 (595)
Hi
Heat m
3
/min (ft
3
/min) 16.4 (580)
Cool m
3
/min (ft
3
/min) 17.60 (621)
Indoor
Airflow
SHi
Heat m
3
/min (ft
3
/min) 17.71 (625)
Cool m
3
/min (ft
3
/min) 54.5 (1925) 56.5 (1995)
Outdoor
Airflow
Hi
Heat m
3
/min (ft
3
/min) 54.5 (1925) 56.5 (1995)
Control Device Expansion Valve
Refrigerant Oil cm
3
FV50S (800)
Refrigeration
Cycle
Refrigerant Type g (oz) R410A, 1.60k (56.5)
Height(I/D / O/D) mm (inch) 290 (11-7/16) / 795 (31-5/16)
Width (I/D / O/D) mm (inch) 1070 (42-5/32) / 875 (34-15/32)
Dimension
Depth (I/D / O/D) mm (inch) 240 (9-15/32) / 320 (12-5/8)
Weight Net (I/D / O/D) kg (lb) 12 (26) / 59 (130)
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 12.70 (1/2)
Standard length m (ft) 5.0 (16.4)
Length range (min – max) m (ft) 3 (9.8) ~ 20 (65.6)
I/D & O/D Height different m (ft) 15 (49.2)
Additional Gas Amount g/m (oz/ft) 20 (0.2)
Piping
Length for Additional Gas m (ft) 10 (32.8)
