Panasonic CS-E21NKEW Service Manual

9
Type Cross-Flow Fan Cross-Flow Fan
Material ASG20K1 ASG20K1
Motor Type Transistor (8-poles) Transistor (8-poles)
Input Power W 94.8 94.8
Output Power W 40 40
Cool rpm 600 700
QLo
Heat rpm 640 870
Cool rpm 800 840
Lo
Heat rpm 980 1050
Cool rpm 1030 1050
Me
Heat rpm 1140 1200
Cool rpm 1260 1270
Hi
Heat rpm 1300 1350
Cool rpm 1290 1310
Indoor Fan
Speed
SHi
Heat rpm 1310 1370
Type Propeller Fan Propeller Fan
Material PP PP
Motor Type DC Motor (8-poles) Induction (6-poles)
Input Power W - -
Output Power W 40 30
Outdoor Fan
Speed Hi rpm 900 910
Moisture Removal L/h (Pt/h) 2.0 (4.2) 2.4 (5.1)
Cool m
3
/min (ft
3
/min) 5.10 (180) 6.10 (215)
QLo
Heat m
3
/min (ft
3
/min) 5.40 (191) 8.00 (282)
Cool m
3
/min (ft
3
/min) 7.35 (260) 7.70 (272)
Lo
Heat m
3
/min (ft
3
/min) 9.20 (325) 10.05 (355)
Cool m
3
/min (ft
3
/min) 9.90 (350) 10.10 (357)
Me
Heat m
3
/min (ft
3
/min) 11.00 (388) 11.70 (413)
Cool m
3
/min (ft
3
/min) 12.5 (440) 12.5 (440)
Hi
Heat m
3
/min (ft
3
/min) 12.8 (450) 13.4 (475)
Cool m
3
/min (ft
3
/min) 13.10 (463) 13.30 (470)
Indoor
Airflow
SHi
Heat m
3
/min (ft
3
/min) 13.30 (470) 13.60 (480)
Cool m
3
/min (ft
3
/min) 33.3 (1175) 33.3 (1175)
Outdoor
Airflow
Hi
Heat m
3
/min (ft
3
/min) 33.3 (1175) 33.3 (1175)
Control Device Check Valve & Capillary Tube Check Valve & Capillary Tube
Refrigerant Oil cm
3
FV50S (320) FV50S (400)
Refrigeration
Cycle
Refrigerant Type g (oz) R410A, 1.01k (35.7) R410A, 1.01k (35.7)
Height(I/D / O/D) mm (inch) 290 (11-7/16) / 619 (24-3/8) 290 (11-7/16) / 619 (24-3/8)
Width (I/D / O/D) mm (inch) 870 (34-9/32) / 824 (32-15/32) 870 (34-9/32) / 824 (32-15/32)
Dimension
Depth (I/D / O/D) mm (inch) 214 (8-7/16) / 299 (11-25/32) 214 (8-7/16) / 299 (11-25/32)
Weight Net (I/D / O/D) kg (lb) 9 (20) / 34 (75) 9 (20) / 33 (73)
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 9.52 (3/8) 6.35 (1/4) / 12.70 (1/2)
Standard length m (ft) 5 (16.4) 5 (16.4)
Length range (min – max) m (ft) 3 (9.8) ~ 15 (49.2) 3 (9.8) ~ 15 (49.2)
I/D & O/D Height different m (ft) 15.0 (49.2) 15.0 (49.2)
Additional Gas Amount g/m (oz/ft) 20 (0.2) 20 (0.2)
Piping
Length for Additional Gas m (ft) 7.5 (24.6) 7.5 (24.6)
