Panasonic CS-E9BKP Supplemental Service Manual

New
Piping size Common
Length
(m)
Max.
Elevation
(m)
Max.
Piping
Length
(m)
Additional
Refrigerant
(g/m)
Model Gas Liquid
E9BK 3/8” 1/4” 7.5 5 15 10
2.2.4. Low Pressure Control (Gas Leakage Detection) (Page: 29)
Conditions E9BKP E12BKP
Cooling/Soft Dry Heating Cooling/Soft Dry Heating
1. Compressor frequency (Hz) 47 56 67 68.5
Note: Conditions 1 and 2 needed to be happened continuously for 5 minutes.
2.2.5. Low Operation Frequency Protection Control (Page: 30)
Temperature, T, for: Cooling/Soft Dry Heating
Indoor intake air (°C) T<15orT 30 —
Outdoor air (°C) T<16orT 38 T<4orT 24
2.2.6. Anti-Fog Discharge Control (Page: 32)
Operation time, T (min) E9BKP E12BKP
0<T 30 Max 33 Hz Max 44 Hz
30 < T 90 Max 26 Hz Max 36 Hz
90 < T 420 Max 26 Hz Max 36 Hz
2.2.7. Intake Air Temperature Control (Page: 33)
1. When the intake air temperature is 10°C or above and remote controller setting fan speed is Lo or lower.
2.2.8. Auto Clean Deice Control (Page: 34)
3 Installation Instructions (Page: 54)
5
CS-E9BKP CU-E9BKP5 / CS-E12BKP CU-E12BKP5
