15 Replacement Parts List
<Model: CS-E9CKP / CS-E12CKP>
REF NO. DESCRIPTION & NAME QTY. CS-E9CKP CS-E12CKP REMARKS
1 CHASSY COMPLETE 1 CWD50C1246
←
2 FAN MOTOR 1 CWA981056
←
O
3 CROSS-FLOW FAN COMPLETE 1 CWH02C1012
←
4 SCREW - CROSS-FLOW FAN 1 CWH4580304
←
5 BEARING ASSY 1 CWH64K007
←
6 EVAPORATOR 1 CWB30C1259 CWB30C1260
7 FLARE NUT (1/4) 1 CWH6002140
←
8 FLARE NUT 1 CWT25005 (3/8) CWT25007 (1/2)
9 ANTI-VIBRATION BUSHING 1 - -
10 INTAKE AIR SENSOR HOLDER 1 CWH32142
←
11 DISCHARGE GRILLE COMPLETE 1 CWE20C2120
←
12 VANE 12 CWE241088
←
13 CONNECTING BAR 2 CWE261035
←
14 AIR SWING MOTOR 2 CWA98260
←
O
15 LEADWIRE 1 CWA67C3849
←
16 FULCRUM 1 CWH621013
←
17 LEADWIRE - AIR SWING MOTOR 1 CWA67C3977
←
18 CAP COMPLETE 1 CWH52C1001
←
19 VANE 1 CWE241070
←
20 PARTICULAR PIECE 1 CWD932162
←
21 CONTROL BOARD 1 CWH102103
←
22 TERMINAL BOARD COMPLETE 1 CWA28C2128
←
O
23 POWER SUPPLY CORD 1 CWA20C2208 CWA20C2238
24 ELECTRONIC CONTROLLER-MAIN 1 CWA73C1361 CWA73C1362 O
25 ELECTRONIC CONTROLLER -P.SUPPLY 1 CWA742616
←
O
26 PCB RECEIVER 1 CWA73C1124
←
27 INDICATOR COMPLETE 1 CWE39C1067
←
28 INDICATOR HOLDER 1 CWD932163
←
29 SENSOR COMPLETE 1 CWA50C2122
←
O
30 CONTROL BOARD COVER (TOP) 1 CWH131091
←
31 CONTROL BOARD COVER (FRONT) 1 CWH131090
←
32 REMOTE CONTROL COMPLETE 1 CWA75C2295
←
O
33 FRONT GRILLE COMPLETE 1 CWE11C2756
←
34 INTAKE GRILLE 1 CWE22C1081
←
35 GRILLE DOOR 1 CWE141033
←
36 DECORATION BASE (RIGHT) 1 CWE351067
←
37 DECORATION BASE (LEFT) 1 CWE351068
←
38 AIR FILTER 2 CWD001047
←
39 CONTROL PANEL 1 CWE312291
←
40 SCREW FOR FRONT GRILLE 2 XTN4+16C
←
41 CAP FOR FRONT GRILLE 2 CWH521062
←
42 DRAIN HOSE 1 CWH85285
←
43 INSTALLING HOLDER ASSY 1 CWH36K1006
←
44 BAG COMPLETE FOR INSTALLATION 1 CWH82C067
←
45 AIR PURIFYING FILTER 1 CWMD00C0001
←
O
46 TRIPLE DEODORIZING FILTER 1 CWMD00C0004
←
O
47 ELECTRONIC CONTROLLER - IONIZER 1 CWA743099
←
48 CASING - IONIZER 1 CWD932228
←
49 ION GENERATOR 1 CWH94C0001
←
(Note)
•
All parts are supplied from MAICO, Malaysia (Vendor Code: 061).
•
“O” marked parts are recommended to be kept in stock.
