10
4.1.4. CS-F24DB4E5 CU-YL43HBE5
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature of 20°C D.B. (68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F
D.B.), 6°C W.B. (42.8°F W.B.)
ELECTRICAL DATA (50 Hz)
ITEM / MODEL
Indoor Unit Outdoor Unit
Main Body CS-F24DB4E5 x 2 CU-YL43HBE5
Panel CZ-BT03P
Remote
Control
CZ-RD513C (Wired)
CZ-RL513B (Wireless)
Cooling Capacity kW 12.5 (3.8 ~ 13.0)
BTU/h 42,700 (13,000 ~ 44,400)
Heating Capacity kW 14.0 (3.8 ~ 15.0)
BTU/h 47,800 (13,000 ~ 51,200)
Refrigerant Charge-less m 30
Standard Air Volume for High,
m
3
/min
Hi 18 Me 16 Lo 14 Hi 96
Medium and Low Speed cfm 636 562 488 3389
Outside Dimension (H x W x D) mm 246 x 840 x 840 1170 x 900 x 320
inch 9-11/16 x 33-1/24 x 33-1/24 46-1/16 x 35-7/16 x 12-19/32
Net Weight kg (lbs) 26 (58) 94 (207)
Piping
Connection
Refrigerant
Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 9.53 (3/8) Flared Type
Drain mm O.D Ø 20 I.D Ø 20 x 1
Compressor Type, Number of Set - Hermetic - 2P (Rotary), 1
Starting Method - DC - INV control
Motor
Type - 4-pole single phase brushless motor
Rated Output kW - 3.4
Fan Type, Number of Set Turbo fan-1 Mix flow fan - 2
Motor
Type 8-pole DC motor 6-pole single phase induction motor
Rated Output kW 0.04 x 2 0.07 x 2
Air-heat Exchanger (Row x Stage x FPI) Slit-fin type (2 x 10 x 20) Corrugate-fin type (2 x 44 x 19)
Refrigerant Control - Exp. Valve
Refrigerant Oil (Charged)
cm
3
- FV50S (1200)
Refrigerant (Charged) R410A kg (oz) - 2.9 (102)
Running
Adjustment
Control Switch Wireless or Wired Remote Control -
Room Temperature Thermostat -
Safety Devices Temperature, current and pressure protection control for compressor,
Internal thermostat for FM, High pressure switch,
Current trans, Crankcase heater
Noise Level dB (A) Hi 36 Lo 32 Cooling 54, Heating 56
Power level dB
Cooling : Hi 51 Lo 47
Heating : Hi 51 Lo 47
Cooling 72, Heating 73
Moisture Removal L/h (Pt/h) 7.9 (16.6)
EER W/W 3.01 (3.04 ~ 2.92)
COP W/W 3.41 (3.45 ~ 3.06)
ITEM / MODEL Condition by ISO5151
Volts V 220 230 240
Phase Single Single Single
Power Consumption kW Cool 4.15 (1.25 ~ 4.45)
Heat 4.10 (1.1 ~ 4.9)
Running Current A Cool 19.7 19.0 18.4
Heat 19.5 18.8 18.2
Starting Current A 19.7 19 18.4
Power Factor % Cool 96 95 94
Heat 96 95 94
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 1~220V, 230V, 240V 50Hz
