Panasonic CS-V7BKPG User Manual

20 Replacement Parts List
<Model: CU-2V18BKP5G>
NO. DESCRIPTION & NAME Q’TY CU-2V18BKP5G REMARKS
1 CHASSY ASS’Y 1 CWD50K663A
2 AIR GUIDER FOR PROPELLER FAN 1 CWD31094A
3 SOUND PROOF BOARD 1 CWH15071
4 FAN MOTOR BRACKET 1 CWD54179
5 CONDENSER 1 CWB322216
6 FAN MOTOR 1 CWA951203 0
7 PROPELLER FAN 1 CWH00023
8 COMPRESSOR 2 GB102PAB 0
9 2-WAY VALVE (LIQUID SIDE) (1/4”) 1 CWB021086 0
10 3-WAY VALVE (GAS SIDE) (3/8”) 2 CWB011107 0
11 HOLDER COUPLING 1 CWH35083A
12 CAPILLARY TUBE 2 CWB152181
13 CONTROL BOARD 1 CWH102151
14 CAPACITOR - COMPRESSOR 2 DS371306CPNA
(370VAC, 30µF)
0
15 CAPACITOR - FAN MOTOR 1 F0GAH305A002
(450VAC, 3µF)
0
18 TERMINAL BOARD 1 CWA281006 0
19 OVERLOAD PROTECTOR 2 CWA121059 0
20 WASHER - TERMINAL COVER 2 CWH571022
21 TERMINAL COVER - COMPRESSOR 2 CWH171021
22 CABINET TOP PLATE 1 CWE03C026
23 CONTROL BOARD COVER 1 CWH13244
24 CABINET FRONT PLATE 1 CWE06C110A
25 CABINET SIDE PLATE 1 CWE04069A
26 FAN GUARD 1 CWD04183
27 HANDLE 1 CWE16000E
28 SOUND - PROOF MATERIAL 2 CWG302141
29 ANTI - VIBRATION BUSHING 6 CWH501024
30 STRAINER 2 CWB11002
31 OPERATING INSTRUCTION 1 CWF563539
32 INSTALLATION INSTRUCTION 1 CWF612290
33 NUT - COMPRESSOR 6 CWH56000
34 HOLDER CAPACITOR - COMP. 2 CWH30078
35 NUT TERMINAL COVER 2 CWH561020
36 MAGNETIC RELAY 2 CWA4000088
37 TERMINAL BOARD ASS’Y 1 CWA28K234
38 TERMINAL BOARD 1 CWA4711012
39 ELECTRONIC CONTROLLER 1 CWA742811
40 HOLDER CAPACITOR - FAN 1 CWH301005
41 SCREW - BRACKET FAN MOTOR 4 CWH55027
42 WASHER - PROPELLER FAN 1 CWH57066
43 WASHER - PROPELLER FAN 1 CWH57067
44 NUT - PROPELLER FAN 1 CWH56033
45 LEAD WIRE COMPLETE - COMPRESSOR 1 CWA67C4205
46 LEAD WIRE COMPLETE - COMPRESSOR 1 CWA67C4206
47 TUBE ASS’Y (STRAINER, CAP.) 1 CWT01C2480
48 TUBE ASS’Y (STRAINER, CAP.) 1 CWT01C2481
49 2-WAY VALVE (LIQUID SIDE) 1 CWB021087 O
(Note)
• All parts are supplied from MAICO, Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
