18 Replacement Parts List
<Model: CU-W7CK / CU-W9CK / CU-W12CK>
REF. NO. PART NAME & DESCRIPTION QTY. CU-W7CKP5 CU-W9CKP5 CU-W12CKP5 REMARKS
1 CHASSY ASS’Y 1 CWD50K2073
←
CWD50K2074
2 SOUND PROOF MATERIAL 1 CWG302088
← ←
3 FAN MOTOR BRACKET 1 CWD541030
← ←
4 SCREW - FAN MOTOR BRACKET 2 CWH55413
← ←
5 FAN MOTOR 1 CWA951119
←
CWA951121 0
6 SCREW - FAN MOTOR MOUNT 3 CWH55406
← ←
7 PROPELLER FAN ASS’Y 1 CWH03K1006
← ←
8 NUT - PROPELLER FAN 1 CWH56053
← ←
9 COMPRESSOR 1 GB080PAA GB102PAA GB134PAA 0
10 ANTI - VIBRATION BUSHING 3 CWH501024
← ←
11 NUT - COMPRESSOR MOUNT 3 CWH56000
←
CWH4582065
12 CONDENSER 1 CWB32C1116
←
CWB32C1108
13 4-WAY VALVE 1 CWB001011
← ←
14 STRAINER 1 CWB11025
← ←
15 HOLDER COUPLING ASS’Y 1 CWH351023
← ←
16 2-WAY VALVE (LIQUID) 1 CWB021057
← ←
0
17 3-WAY VALVE (GAS) 1 CWB011063
←
CWB011062 0
18 OVERLOAD PROTECTOR 1 CWA121058 CWA121059 CWA121057 0
19 TERMINAL COVER 1 CWH171021
← ←
20 NUT - TERMINAL COVER 1 CWH561020
← ←
21 SOUND PROOF BOARD 1 CWH151022
←
CWH151023
22 CONTROL BOARD 1 CWH102102
← ←
23 TERMINAL BOARD ASS’Y 1 CWA28K216
← ←
24 CAPACITOR - COMPRESSOR 1 DS371256CPNA
(25µF, 370VAC)
DS371306CPNA
(30µF, 370VAC)
DS371356CPNA
(35µF, 370VAC)
0
25 HOLDER CAPACITOR 1 CWH30057
← ←
26 CAPACITOR - FAN MOTOR 1 CWA31618
(2.0µF, 450VAC)
← ←
0
27 CABINET SIDE PLATE (L) 1 CWE041031A
← ←
28 CABINET SIDE PLATE (R) 1 CWE041032A
←
CWE041033A
29 CABINET FRONT PLATE 1 CWE06K1034
← ←
30 WIRE NET 1 CWD041021A
←
CWD041023A
31 CABINET TOP PLATE 1 CWE031014A
← ←
32 PLATE - C. B. COVER 1 CWH131088
← ←
33 CONTROL BOARD COVER 1 CWH131092
← ←
34 HANDLE 1 CWE161010
← ←
35 OPERATION INSTRUCTIONS 1 CWF563838
← ←
36 INSTALLATION INSTRUCTIONS (ENGLISH,
FRANCAIS, ESPANOL & DEUTSCH)
1 CWF612304
← ←
37 INSTALLATION INSTRUCTIONS (ITALIANO,
NEDERLANDS, PORTUGUES & GREEK)
1 CWF612305
← ←
38 INSTALLATION INSTRUCTIONS (RUSSIA) 1 CWF612306
← ←
39 L-TUBE 1 CWH5850080
← ←
40 TUBE ASS’Y (CHECK VALVE/CAPILLARY) 1 CWT01C2653 CWT01C2654 CWT01C2648
41 ELECTRO MAGNETIC SWITCH 1 CWA00059
← ←
42 ELECTROLYTIC CAPACITOR 1 CWA32C067
← ←
43 ELECTRO MAGNETIC SWITCH 1 K6C2C7A00001
←
K6A2C7A00002
44 TEMPERATURE RELAY 1 CWA14C1009
← ←
45 V-COIL COMPLETE 1 CWA43C2069
← ←
(Note)
•
All parts are supplied from MAICO, Malaysia (Vendor Code: 061).
•
“O” marked parts are recommended to be kept in stock.
79
CS-W7CKP CU-W7CKP5 / CS-W9CKP CU-W9CKP5 / CS-W12CKP CU-W12CKP5
