MODEL / ITEM
CS-A50BD2P/CU-A50BBP8
Condition by JIS B 8616
Volts V 380 400 415
Phase 3N 3N 3N
Input Power kW Cool 5.10 5.10 5.10
Heat 4.7 4.7 4.7
Running Current A Cool 9.2 9.2 9.2
Heat 8.9 8.9 8.9
Starting Current A 69 69 69
Power Factor % Cool 84 80 77
Heat 80 76 73
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power
source
AC, 3N~380V, 400V, 415V 50Hz
4. SPECIFICATION (COOLING ONLY TYPE)
4.1 CS-A24BD2P / CU-C24BBP5
37
