ITEM / MODEL
Indoor Unit Outdoor unit
Main Body CS-A24BD2P CU-C24BBP5
Cooling Capacity kW 6.50
(BTU/h) (22,200)
Refrigerant Charge-less m 30
Standard Air Volume for High
m
3
/min
Hi 18 Hi 43
Medium and Low Speed cfm Hi 636 1518
External Static Pressure mmAq Hi 10 Me 7 Lo 5 -
Pa Hi 98 Me 69 Lo 40
Air Inlet Backward Suction Rear sided Suction
Air Outlet Front blow-out Front blow-out
Outside Dimension (H x W x D) mm 290 x (1000 + 100) x 500 900 x 900 x 320
Net Weight kg (lbs) 40 (88) 80 (176)
Piping
Connection
Refrigerant
Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 6.35 (1/4) Flared Type
Drain mm Female screw RC1 (PT1) I.DØ 20 x 1
Compressor
Type, Number of Set - Hermetic-1 (Rotary), 1
Starting
Method
- Direct on-line starting
Motor Type - 2-pole single phase
induction motor
Input kW - Cool/2.31
Rated
Output
kW - 1.9
38
