Name of Each Part
Indoor unit
Operation Indication
Lamps (LED)
(Rear)
(Side)
Outdoor unit
Air Intake Vents
Air Outlet Vents
Drain Hose
Piping
Ground Terminal
(Inside Cover)
Front Panel
Air Intake Vent
Air Outlet Vent
Panel Opener
Horizontal
Airflow Direction Louver
(Manually adjusted)
Vertical Airflow
Direction Louver
Signal Receptor
Power Sleep Timer
Red Orange Orange
25
CS-A28BKP5/CU-A28BKP5
