Panasonic CU-A34BBP5 - Page 145

17 15.00 13.95 4.42
14.4213.70
4.74
13.7013.43
5.06
12.8412.84
5.39
11.8311.83
5.66
29 19 15.72 12.11 4.74
15.1511.97
5.06
14.4211.68
5.39
13.7011.37
5.72
12.8410.91
5.98
22 17.02 9.36 5.28
16.44
9.37 5.55
15.72
9.28 5.88
15.00
9.15 6.14
14.14
8.91 6.47
17 14.88 13.84 4.42
14.3113.59
4.74
13.5913.32
5.06
12.7412.74
5.39
11.7311.73
5.66
32 19 15.60 12.01 4.74
15.0311.87
5.06
14.3111.59
5.39
13.5911.28
5.72
12.7410.83
5.98
22 16.89 9.29 5.28
16.31
9.30 5.55
15.60
9.20 5.88
14.88
9.08 6.14
14.02
8.83 6.47
Legend: BF Bypass Factor 0.22 SHC Sensible Heat Capacity TC Total Cooling Capacity / CAPACITY SELECTION NOTES / (1) The table above
is based on unit nominal evaporator airflow, / correction factor must therefore be applied for selections / away from this condition. /
COOLING CORRECTION FACTORS
EVAP. AIR FLOW m
3
/
min (l/s)
37 (617) 41 (683) 45 (750) 49 (817)
SHC Sensible Heat
Capacity
0.90 0.93 1.0 1.07
TC Total Cooling
Capacity
0.92 0.96 1.0 1.04
15.3. HEATING CAPACITY CURVE, HEATING POWER CONSUMPTION CURVE (HEAT PUMP MODEL
ONLY)
HEATING CAPACITY CURVE
145
