9. OPERATION RANGE
Power Supply / The applicable voltage range for each unit is given in “the following table”. The working voltage among the three phases
must be balanced within 3% deviation from each voltage at the compressor terminals. The starting voltage must be higher than 85% of the
rated voltage. / / / Power Supply
Model-
CU
Unit Main Power Applicable Voltage Model-CU Unit Main Power Applicable Voltage
Phase,
Volts
Hz Maximum Minimum Phase,
Volts
Hz Maximum Minimum
A24BBP5
A28BBP5
A34BBP5
C24BBP5
C28BBP5
C34BBP5
1~220 50 242 198 A28BBP8
A34BBP8
A43BBP8
A50BBP8
C28BBP8
C34BBP8
C43BBP8
C50BBP8
3N~380 50 418 342
1~230 50 253 207 3N~400 50 440 360
1~240 50 254 216 3N~415 50 457 374
Indoor and Outdoor Temperature All Models
Operating Hz
Indoor Temp. (D.B./W.B.) (°C) Outdoor Temp. (D.B./W.B.) (°C)
Maximum Minimum Maximum Minimum
Cooling 50 32/23 21/15 43/- -5/-
Heating 50 27/- 16/- 24/18 -10/-
107
