Panasonic CU-A50BBP8 - Page 143

Ambient Temperature Air Entering Condenser (°C D.B.)
Return 25°C 30°C 35°C 40°C 45°C
Air TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT
D.B. W.B. kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW
17 13.69 12.18 3.66
13.1611.98
3.93
12.5011.75
4.19
11.7111.24
4.46
10.7910.79
4.69
23 19 14.35 10.47 3.93
13.8210.36
4.19
13.1610.13
4.46
12.50
9.87 4.73
11.71
9.48 4.95
22 15.53 7.92 4.37
15.00
7.95 4.60
14.35
7.89 4.86
13.69
7.80 5.08
12.89
7.61 5.35
17 13.60 12.10 3.66
13.0811.90
3.93
12.4311.68
4.19
11.6311.17
4.46
10.7310.73
4.69
25 19 14.25 10.40 3.93
13.7310.29
4.19
13.0810.07
4.46
12.43
9.82 4.73
11.63
9.43 4.95
22 15.43 7.87 4.37
14.90
7.90 4.60
14.25
7.84 4.86
13.60
7.75 5.08
12.82
7.56 5.35
17 13.52 12.17 3.66
13.0011.96
3.93
12.3511.73
4.19
11.5711.22
4.46
10.6610.66
4.69
27 19 14.17 10.49 3.93
13.6510.37
4.19
13.0010.14
4.46
12.35
9.88 4.73
11.57
9.49 4.95
22 15.34 7.97 4.37
14.82
8.00 4.60
14.17
7.93 4.86
13.52
7.84 5.08
12.74
7.65 5.35
17 13.45 11.97 3.66
12.9311.77
3.93
12.2811.55
4.19
11.5111.05
4.46
10.6010.60
4.69
29 19 14.10 10.29 3.93
13.5810.18
4.19
12.93
9.96 4.46
12.28
9.70 4.73
11.51
9.32 4.95
22 15.26 7.78 4.37
14.74
7.81 4.60
14.10
7.75 4.86
13.45
7.67 5.08
12.98
7.48 5.35
17 13.34 11.87 3.66
12.8311.67
3.93
12.1911.46
4.19
11.4210.96
4.46
10.5210.52
4.69
32 19 13.98 10.21 3.93
13.4710.10
4.19
12.83
9.87 4.46
12.19
9.63 4.73
11.42
9.25 4.95
22 14.80 7.72 4.37
14.63
7.75 4.60
13.98
7.69 4.86
13.34
7.61 5.08
12.57
7.42 5.35
Legend: BF Bypass Factor 0.21 SHC Sensible Heat Capacity TC Total Cooling Capacity / CAPACITY SELECTION NOTES / (1) The table above
is based on unit nominal evaporator airflow, / correction factor must therefore be applied for selections / away from this condition. /
