MODEL / ITEM
CS-A34BD2P/CU-C34BBP5
Condition by JIS B 8616
Volts V 220 230 240
Phase Single Single Single
Input Power kW Cool 3.95 3.95 3.95
Running Current A Cool 19.0 19.1 19.2
Starting Current A 94 99 103
Power Factor % Cool 94 90 87
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power
source
AC, 1~220V, 230V, 240V 50Hz
4.5 CS-A34BD2P / CU-C34BBP8
ITEM / MODEL
Indoor Unit Outdoor unit
Main Body CS-A34BD2P CU-C34BBP8
Cooling Capacity kW 10.45
(BTU/h) (35,600)
Refrigerant Charge-less m 30
Standard Air Volume for High
m
3
/min
Hi 35 Hi 70
Medium and Low Speed cfm Hi 1236 2471
External Static Pressure mmAq Hi 10 Me 7 Lo 5 -
Pa Hi 98 Me 69 Lo 49
Air Inlet Backward Suction Rear sided Suction
Air Outlet Front blow-out Front blow-out
Outside Dimension (H x W x D) mm 360 x (1000 + 10) x 650 1220 x 900 x 320
Net Weight kg (lbs) 54 (119) 97 (214)
47
