Note:
Dimensions Height inch (mm) 10 - 13/16 (275) 21 - 1/4 (540)
Width inch (mm) 31 - 15/32 (799) 30 - 23/32 (780)
Depth inch (mm) 8 - 9/32 (210) 11 - 3/8 (289)
Net Weight lb (kg) 20 (9.0) 64 (29.0)
Compressor Type — Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output W — 550
Air Circulation Type Cross-flow Fan Propeller Fan
Material AS + Glass Fiber 20% PP Resin
Motor Type Induction (4-poles) Induction (6-poles)
Input W 44.8 - 53.5 57.0 - 62.0
Rate Output W 15 29
Fan Speed Low rpm Cooling; 780 - 780 —
Heating; 840 - 840
Medium rpm Cooling; 920 - 920 —
Heating; 920 - 920
High rpm Cooling; 1,030 - 1,030 805 - 820
Heating; 1,190 - 1,190
SuperHigh rpm Cooling; 1,190 - 1,190 —
Heating; 1,190 - 1,190
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium (Pre Coat) Aluminium (Blue Coat)
Fin Type Slit Fin Corrugate Fin
Row / Stage (Plate fin configuration, forced draft)
2×15 1×20
FPI 19 17
Size (W × H × L) mm 610 × 315 × 25.4 841 × 508 × 22
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (cm
3
) — SUNISO 4GDID or ATMOS
M60 (290)
Refrigerant (R-22) g (oz) — 810 (28.6)
Thermostat Electronic Control —
Protection Device — Overload Protector
Capillary Tube Length mm — Cooling; 600, Heating; 650
Flow Rate l/min — Cooling; 5.0, Heating; 11.4
Inner Diameter mm — Cooling; 1.1, Heating; 1.5
Air Filter Material
Style
P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 20 µF, 370VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 400VAC 2.0 µF, 450VAC
• Specifications are subject to change without notice for further improvement.
• (1) — CS-A7BKP/CU-A7BKP5 (Europe).
• (2) — CS-A7BKP-2/CU-A7BKP5-2 (Oceania).
• (4) — CS-A7BKP-6/CU-A7BKP5-6 (Turkey).
7
CS-A7BKP CU-A7BKP5 / CS-A7BKP CU-A7BKP6 / CS-A9BKP CU-A9BKP5 / CS-A9BKP CU-A9BKP6 / CS-A12BKP CU-A12BKP5 / CS-A12BKP CU-A12BKP6
