Panasonic CU-B34DBE5 - Page 125

125
HC: Heating Capacity IPT: Heating Power Consumption
Model Heating capacities are based on conditions
CS-F34DB4E5 3 phase, 50Hz 400V
Heating capacity Indoor temp. 20°C D.B.
11.2kW Outdoor temp. 7°C D.B. 6°C W.B.
Standard air volume 27 m
3
/min
Ambient Temperature Air Entering Condenser (°C D.B.)
Return -6°C0°C6°C12°C
Air HCHCHCHC
D.B. kW kW kW kW
15 8.18 9.80 11.76 13.66
20 7.73 9.24 11.20 13.44
25 7.28 8.74 10.64 12.88
Ambient Temperature Air Entering Condenser (°C D.B.)
Return -6°C0°C6°C12°C
Air IPT IPT IPT IPT
D.B. kW kW kW kW
15 2.65 3.02 3.59 4.23
20 2.80 3.21 3.78 4.38
25 2.95 3.40 3.97 4.48
