124
HC: Heating Capacity IPT: Heating Power Consumption
Model Heating capacities are based on conditions
CS-F34DB4E5 Single phase, 50Hz 230V
Heating capacity Indoor temp. 20°C D.B.
11.2kW Outdoor temp. 7°C D.B. 6°C W.B.
Standard air volume 27 m
3
/min
Ambient Temperature Air Entering Condenser (°C D.B.)
Return -6°C0°C6°C12°C
Air HCHCHCHC
D.B. kW kW kW kW
15 8.18 9.80 11.76 13.66
20 7.73 9.24 11.20 13.44
25 7.28 8.74 10.64 12.88
Ambient Temperature Air Entering Condenser (°C D.B.)
Return -6°C0°C6°C12°C
Air IPT IPT IPT IPT
D.B. kW kW kW kW
15 2.70 3.09 3.67 4.32
20 2.86 3.28 3.86 4.48
25 3.01 3.47 4.05 4.57
