49
NO.
PART NAME QTY. CS-RE9NKX CS-RE12NKX CS-RE15NKX
REMARK
1
CHASSIS COMPLETE 1 CWD50C1644 CWD50C1644 CWD50C1738
2
FAN MOTOR(DC,280-340V,30W) 1 ARW7648AC ARW7648AC ARW7648AC
3
CROSS FLOW FAN COMPLETE 1 CWH02C1095 CWH02C1095 CWH02C1095
4
BEARING ASS'Y 1 CWH64K1008 CWH64K1008 CWH64K1008
5
EVAPORATOR 1 CWB30C3981 CWB30C3977 CWB30C3978
6
AUXILIARY TUBE ASS'Y 1 CWT01C5455 CWT01C5455 CWT01C5456
7
DRAIN PLUG 1 CWH521096 CWH521096 CWH521096
8
DISCHARGE GRILLE COMPLETE 1 CWE20C3276 CWE20C3276 CWE20C3276
9
AIR SWING
MOTOR(DC,12V,200OHM)
1 CWA981292 CWA981292 CWA981292
10
HORIZONTAL AIR FLOW VANE (L) 1 CWE24C1292 CWE24C1292 CWE24C1292
11
HORIZONTAL AIR FLOW VANE (R) 1 CWE24C1291 CWE24C1291 CWE24C1291
12
VERTICAL AIR FLOW VANE 1 CWE24C1413 CWE24C1413 CWE24C1413
13
CONTROL BOX COMPLETE 1 CWH14C9275 CWH14C9276 CWH14C9279
14
CONTROL BOARD CASING 1 CWH102487 CWH102487 CWH102487
15
PARTICULAR PIECE 1 CWD933089 CWD933089 CWD933089
16
TERMINAL BOARD COMPLETE 1 CWA28C2546 CWA28C2547 CWA28C2546
17
POWER SUPPLY CORD
COMPLETE
1 CWA20C3068 CWA20C3068 CWA20C3074
18
MAIN PCB 1
CWA73C5921 CWA73C5922 CWA73C5923
19
SENSOR 1 CWA50C2883 CWA50C2883 CWA50C2883
20
INDICATOR HOLDER 1 CWD933546 CWD933546 CWD933546
21
INDICATOR PCB 1 CWA746860 CWA746860 CWA746860
22
CONTROL BOARD TOP COVER 1 CWH131523 CWH131523 CWH131523
23
CONTROL BOARD BACK COVER 1 CWH131526 CWH131526 CWH131526
24
REMOTE CONTROL 1 CWA75C3755 CWA75C3755 CWA75C3755
25
FRONT GRILLE COMPLETE 1 CWE11C5307 CWE11C5307 CWE11C5307
26
INTAKE GRILLE 1 CWE22K1594 CWE22K1594 CWE22K1594
27
GRILLE DOOR 1 CWE14C1092 CWE14C1092 CWE14C1092
28
AIR FILTER 2 CWD001339 CWD001339 CWD001339
29
ANTI-BACTERIAL FILTER 1 CWD001280 CWD001280 CWD001280
30
SCREW-FRONT GRILLE 2 XTT4+16CFJ XTT4+16CFJ XTT4+16CFJ
31
CAP-FRONT GRILLE 2 CWH521236A CWH521236A CWH521236A
32
DRAIN HOSE
1
CWH851136 CWH851136 CWH851136
33
OPERATING INSTRUTIONS
1
CWF568412 CWCWF568412 CWF568412
34
INSTALLATION INSTRUCTION
1
CWF615235 CWCWF615235 CWF615235
35
INSTALLATION INSTRUCTION
1
CWF615236 CWCWF615236 CWF615236
36
INSTALLATION PLATE
1
CWH361133 CWH361133 CWH361133
(Note)
• All parts are supplied from PAPAGZ, China
