Panasonic CW-XC120VK User Manual

16 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

INSTALLATION AND

OPERATING INSTRUCTIONS

MODEL: CW-XC100VK

CW-XC120VK

ROOM AIR CONDITIONER

F563665

Please read these operating instructions thoroughly before using

your air conditioner and keep them for future reference.

ENGLISH

Table of Contents

Other manuals for Panasonic CW-XC120VK

Service Manual32 pages

Questions and Answers:

J
Jennifer LopezAug 12, 2025
Why is my Panasonic CW-XC120VK not cooling enough?
- E
  Eric MarshallAug 13, 2025
  Insufficient cooling can occur due to several reasons. It might be that the unit's capacity is reduced, in which case you should set it to a lower setting. Restricted air circulation could also be the culprit; try closing the ventilation door or removing any obstacles that might be blocking the airflow, or consider reinstalling the unit. A restricted heat exchanger could also cause this problem. Try cleaning or replacing the air filter. Additionally, consider building an awning. Other potential solutions include cleaning the coils, replacing the unit with a bigger one, locating and repairing any leaks, or flushing the refrigeration cycle.
W
William MendezAug 16, 2025
Why is my Panasonic CW-XC120VK dripping water inside the room?
- C
  Courtney BlackAug 16, 2025
  If your Panasonic Air Conditioner is dripping water inside the room, it could be because the unit is tilted towards the inside. To fix this, tilt the unit slightly to the outside. Also, check for and remove any foreign materials that may be causing the issue.
C
Connie LittleAug 20, 2025
What to do if the fan motor and compressor won't run on my Panasonic CW-XC120VK?
- M
  Michael FlynnAug 20, 2025
  If the fan motor and compressor of your Panasonic Air Conditioner aren't running, try waiting for 3 minutes. If the issue persists, and it seems to be a permanent problem, consult an electrician. Other solutions include repairing an open circuit, repairing or replacing the components, or setting the unit to a lower setting.
D
Dr. Mikayla RasmussenAug 25, 2025
How to reduce noise from my Panasonic Air Conditioner?
- B
  brichardsAug 25, 2025
  Noises from your Panasonic Air Conditioner can stem from several factors. If the installation is faulty, reinstalling the unit or reinforcing the existing installation might help. Adjusting the fan position or removing any foreign materials could also reduce noise. Ensure there's about 1/2" clearance. If water is causing the noise, remove the drain plug and mount a drain pan to remove the water, or set the drain outlet downward to allow water to run off.
E
Erica DavisAug 27, 2025
What to do if the evaporator is frozen in my Panasonic Air Conditioner?
- J
  josephbarberAug 27, 2025
  If you find the evaporator frozen in your Panasonic Air Conditioner, set the Main Control knob to Fan to melt the ice and adjust the Temperature Control to a higher temperature. Also, clean the air filter or evaporator. Other solutions are to locate and repair any leaks, or flush the refrigeration cycle.
J
jill36Aug 31, 2025
Why won't the compressor run on my Panasonic CW-XC120VK, but the fan does?
- B
  Benjamin LynnAug 31, 2025
  If the compressor isn't running but the fan is, try setting it to a lower setting. If that doesn't work, consider replacing the compressor, overload protector, capacitor compressor, or thermostat.
T
tylerallenSep 4, 2025
What to do if the fan motor won’t run on my Panasonic Air Conditioner, but the compressor does?
- P
  pwellsSep 4, 2025
  If the fan motor isn't running while the compressor is, try adjusting the fan position setting screw. Also, remove any foreign materials that may be obstructing it. You might also need to replace the fan motor or the capacitor fan.
A
Arthur PerezSep 8, 2025
How to fix a Panasonic CW-XC120VK Air Conditioner when the air swing won’t run?
- A
  Antonio HuntSep 8, 2025
  If the air swing function isn't working on your Panasonic Air Conditioner, first ensure that the air swing is set to 'ON'. If it still doesn't work, you may need to replace the air swing switch or the air swing motor.
