Panasonic DBUB-P207

Specification
Power supply DC 3.3V 38.5mA(typical)
Antenna Tx 1, Rx 1
Host Interface USB 2.0 + GPIO x1
Standard Compliance Bluetooth 3.0
Frequency Range 2.4 GHz (2.40GHz-2.4835GHz)
Modulation
・GFSK
・Pi/4 QPSK
・8DPSK
Receiver Sensitivity
-88 dBm(typ.) GFSK, 0.1%BER
-85 dBm(typ.) for pi/4-DQPSK, 0.01%BER
Transfer rate (standard)
*
3.0Mbps(MAX, Theoretical Value)
Output Power
Class 2, 0dBm typical, class 2 device (-6dBm < output
power <4dBm).
Security BT E0/AES/SAFER+
* Transfer rate are theoretical values; however, actual communication rate will
vary according to communication environment or connected equipment.
