Panasonic DH-3VS1 - HOW TO INSTALL ELECTRIC HOME SHOWER; BEFORE INSTALLATION

EN12
English
SPECIFICATIONS
SINGAPORE:
Model No. DH-3VS1
Voltage 230 V a.c. 50 Hz
Power Consumption 3000 W
Electric Power Control
Inlet Water Temp. (Off),
1000 W ~ 3000 W
Min. Water Pressure 9.8 kPa / 0.1 kgf/cm² / 1.42 psi / 0.098 bar
Max. Water Pressure 380 kPa / 3.87 kgf/cm² / 55 psi / 3.8 bar
Dimension 380 (H) mm x 190 (W) mm x 82 (D) mm
Weight 1.4 kg
Outlet System Single Point System (Open Outlet)
OTHER DESTINATION:
Model No. DH-3VS1 DH-3VP1
Voltage 220 V a.c. 50 Hz
Power Consumption 3500 W
Electric Power Control
Inlet Water Temp. (Off),
1000 W ~ 3500 W
Min. Water Pressure 9.8 kPa / 0.1 kgf/cm² / 1.42 psi 4.9 kPa / 0.05 kgf/cm² / 0.71 psi
Max. Water Pressure 380 kPa / 3.87 kgf/cm² / 55 psi
Dimension 380 (H) mm x 190 (W) mm x 82 (D) mm
Weight 1.4 kg 2.5 kg
Outlet System Single Point System (Open Outlet)
MALAYSIA:
Model No. DH-3WL1 DH-3VS1 DH-3VP1
Voltage 240 V a.c. 50 Hz
Power Consumption 3600 W
Electric Power Control
Inlet Water Temp. (Off),
1000 W ~ 3600 W
Min. Water Pressure 9.8 kPa / 0.1 kgf/cm² / 1.42 psi 4.9 kPa / 0.05 kgf/cm² / 0.71 psi
Max. Water Pressure 380 kPa / 3.87 kgf/cm² / 55 psi
Dimension 380 (H) mm x 190 (W) mm x 82 (D) mm
Weight 1.4 kg 1.4 kg 2.5 kg
Outlet System Single Point System (Open Outlet)
