Getting started
- 9 -
1 Disc tray (> 15)
2 USB port (> 15)
3 POWER LED
The LED lights up when the unit is turned on,
and flashes when error occurs. (> 33)
4 Remote control signal sensor
Distance: Within approx. 7 m
Angle: Approx. 20e up and down, 30e left and
right
5 Open or close the disc tray (> 15)
6
[BDT271/270] [BDT175/174/171/170]
Stop (> 17)
7
[BDT271/270] [BDT175/174/171/170]
Start play (> 17)
8 Standby/on switch (Í/I) (> 13)
Press to switch the unit from on to standby
mode or vice versa. In standby mode, the unit
is still consuming a small amount of power.
Rear panel terminals (> 10–12)
1 2 3 4
875 6
85
1
2
3
4
[BDT271/270]
[BDT175/174/171/170]
[BDT166/165]
[BD833/83]
