16.2. Replacement Parts List
Notes:
*Important safety notice:
Components identified by mark have special characteristics important for safety.
Furthermore, special parts which have purposes of fire-retardant (resistors), high-quality
sound (capacitors), low-noise (resistors), etc. are used.
When replacing any of components, be sure to use only manufactures specified parts
shown in the parts list.
*Warning: This product uses a laser diode. Refer to caution statements.
*Capacity values are in microfarads ( F) unless specified otherwise, P=Pico-farads (pF), F=
Farads (F).
*Resistance values are in ohms, unless specified otherwise, 1K=1,000 (OHM), 1M=1,000k
(OHM).
*The marking (RTL) indicates the retention time is limited for this item. After the
discontinuation of this assembly in production, it will no longer be available.
*“(IA)-(IF)”, marks in Remarks indicate languages of instruction manuals. [(IA): English/
German, (IB): Spanish/ French, (IC): English, (ID): Polish, (IE): Swedish/ Danish, (IF): Italian/
Dutch]
*Parts indicated with PAVC-CSG in the Remarks column are supplied by PAVC-CSG.
*All parts except parts indicated with (PAVC-CSG) in the Remarks column are supplied by
PAVCG.
Ref. No. Part No. Part Name & Description Pcs Remarks
RFKB79119C MAIN P.C.B. (RTL)EB
RFKB79119DT MAIN P.C.B. (RTL)EP
RFKB79119BT MAIN P.C.B. (RTL)EC
RFKB79119AT MAIN P.C.B. (RTL)EG
RFKB79119D MAIN P.C.B. (RTL)EBL
C1502 F1J1E104A081 25V 0.1U 1
C1503 F2A1A6810022 10V 680P 1
C1504 F2A1E1010067 25V 100U 1
C1506 EEUFM1E221B 25V 220U 1
C1508 ECJ1VB1A105K 10V 1U 1
C1509 F1H1H1030006 50V 0.01U 1
C1510 ECJ1VB1A105K 10V 1U 1
C1511 ECJ1VB1A105K 10V 1U 1
C1512 ECJ1VB1A105K 10V 1U 1
C1515 F2A1E4700048 25V 47U 1
C1518 F2A1A1010072 10V 100U 1
C1520 ECJ1VB1A105K 10V 1U 1
C1522 ECJ1VB1A105K 10V 1U 1
C1523 F2A1A470A388 10V 47U 1
C1524 F2A1A101A389 10V 100U 1
C1525 F1H1C104A042 16V 0.1U 1
C1535 ECJ1VB1A105K 10V 1U 1
C1536 F1J0J106A014 6.3V 10U 1
C1538 ECJ1VB1A105K 10V 1U 1
C1539 ECJ1VB1A105K 10V 1U 1
