4.2. Cautions in Assembly
NOTE:
When reassembling, replace the new waterproof rubber. Make sure whether there is NO foreign substance sticking around a
part covered with water seal.
4.2.1. Motor
Insert the tube into the projection of the housing A and set the
tube holder firmly. Then hook the motor holder to the housing
and put the float springs properly.
4.2.2. Module
Align the projection of switch select button on housing A with
the groove of switch plate on module.
