2 Wiring diagram
FV-05/08/11VF2
11
Motor
Red
Green
Capacitor
White
Neutral
Green
White
Black
White
Black
Green
Live
Earth ground
Power Supply
AC120V 60Hz
Fan body
Junction box
Earth ground
Black
