Main Body Section
No. Part No. Part Name Q'ty Remark
1 FFV5710025S Suspension Bracket 1
2 FFV1600159S Frame Assy 1
3 FFV0000166S Adapter Assy 1
4 FFV0900052S Connector Plate 1
5 FFV3450010S Earth Lead Wire 1
6 FFV0900072S Connector Assy (V) 1
7 FFV2800020S Junction Cover 1
8 FFV4700070S PCB Assy Unit 1
9 FFV3700347S Motor Assy 1
10 FFV3700348S Motor Support Unit 1
11 FFV0400127S Blade Plate 1
12 FFV0400128S Blade 1
13 FFV0400113S Blade Fix Ring 1
14
FFE06090801S Undee Washer 1
15 FFV7020024S Hexagon Nut 1
16 FFV1610080S Casing Unit 1
17 FFV3400146S Louver Assy 1
A FFV7000108S Truss Tap Screw 5
B FFV7000227S Earth Screw Assy 1 Include Spring Washer
C FFV7000089S Truss Tap Screw 6
D FFV7000163S Pan Tap Screw 4
E FFV7000202S Bind Tap Screw 3
Main Labels
No. Part No. Part Name Q'ty Remark
18 FFV4020865S Name Plate 1 Stuck On Casing
19 FFV2260003S UL Mark 1 Stuck On Frame Assy
20 FFV0810011S Caution Label 1 1 Stuck On Frame Assy
To Next Page
