Specifications
1. Specification table
Note: In above table, the values are tested 230V for Single-phase Models, and 380V for Three-phase Models.
1. The values of air volume are measured at 0 static pressure (Pa) by the chamber method.
2. The values of Current and Input are in the free load condition.
3. The values of noise level are measured at 0 static pressure (Pa) and at the following positions.
(When ducts are connected on both inlet and outlet side.)
Side of fan body : 1.5m apart from the fan body (excluding the noise of outlet side)
Inlet side :
1.5m apart from the inlet of the fan (excluding the noise of outlet side)
Outlet side :
1.5m angle 45° apart from outlet side (excluding the noise of inlet side)
Add 2dB to the values above for the noise levels apart from 1.0 m.
4. Specifications above indicate the values under the condition of normal temperature (20 degrees Celsius).
Use in the following conditions
Handling air and Ambient air : -10 to +40 deg C, relative humidity 85% or less
Do not use the product in the places such as outdoor (where rain water splashes), where water splashes, steam is always
generated, corrosive gas may be generated, or chemicals may be used.
Do not use the product in the places such as pools or hot springs where the chemicals such as chlorine are used.
It has high possibility to cause corrosion in a short term.
2. Use condition
Model No. Power supply
Rated
voltage
(V)
Num-
ber of
poles
Output Hi/Lo
Air volume
(m
3
/h)
Current
(A)
Max current
(A)
Input
(W)
Noise level (dB)
Weight
(kg)
Side of body Inlet side Outlet side
50Hz 60Hz 50Hz 60Hz 50Hz 60Hz 50Hz 60Hz 50Hz 60Hz 50Hz 60Hz 50Hz 60Hz
FY-25DSF2NET Single-phase 220-240V 4 25
Hi 600 720 0.19 0.17 0.24 0.22 34 38 41.0 42.0 51.0 54.0 50.5 53.5
4.7
Lo 550 650 0.14 0.12 0.17 0.18 27 29 39.5 41.5 49.0 52.0 48.5 51.5
FY-28DSM2NET Single-phase 220-240V 4 20
Hi 1194 1224 0.25 0.28 0.32 0.35 51 62 44.5 45.5 54.5 55.5 54.0 55.0
8.5
Lo 1050 1062 0.24 0.26 0.30 0.32 55 61 42.0 43.0 52.0 53.0 51.5 52.5
FY-35DSM2NET Single-phase 220-240V 4 60
Hi 2016 2154 0.42 0.57 0.54 0.70 95 131 45.5 46.5 56.5 57.5 56.0 57.0
13.0
Lo 1782 1830 0.38 0.50 0.46 0.57 87 113 43.0 44.0 54.0 55.0 53.5 54.5
FY-40DSL2NET Single-phase 220-240V 4 200
Hi 3228 3528 0.94 1.3 1.2 1.6 204 281 56.0 56.5 68.0 68.5 67.5 68.0
20.0
Lo 3084 3186 0.86 1.1 1.1 1.3 194 245 54.0 54.5 66.0 66.5 65.5 66.0
FY-40DSH2NET Single-phase 220-240V 4 300
Hi 3504 4128 1.1 1.8 1.5 2.3 256 401 55.5 56.5 67.5 68.5 67.0 68.0
22.0
Lo 3444 3822 1.0 1.6 1.4 2.1 233 348 53.5 54.5 65.5 66.5 65.0 66.0
FY-45DST2NET Single-phase 220-240V 4 550
Hi 4968 5940 1.9 2.8 2.4 3.8 428 643 59.5 61.0 69.5 71.0 69.5 71.0
37.0
Lo 4206 5790 1.7 2.7 2.2 2.5 398 615 58.0 60.5 68.0 70.5 68.0 70.5
FY-40DTL2BET Three-phase 380V 4 200
Hi 3396 3840 0.48 0.65 0.63 0.88 241 381 56.0 56.0 68.0 68.0 67.5 67.5
18.0
Lo 3330 3660 0.42 0.59 0.55 0.76 237 334 54.0 54.0 66.0 66.0 65.5 65.5
FY-40DTH2BET Three-phase 380V 4 300
Hi 3426 3912 0.57 0.66 0.68 0.87 250 372 56.0 57.0 68.0 69.0 67.5 68.5
19.0
Lo 3264 3666 0.45 0.58 0.55 0.74 220 331 55.0 56.0 67.0 68.0 66.5 67.5
FY-45DTT2BET Three-phase 380V 4 550
Hi 5004 6000 1.1 1.2 1.3 1.6 421 638 61.0 63.0 71.0 73.0 71.0 73.0
36.0
Lo 4860 5886 0.93 1.1 1.2 1.5 397 614 60.5 62.5 70.5 72.5 70.5
72.5
FY-45DTH2BET Three-phase 380V 4 700
Hi 5454 6522 1.2 1.4 1.5 1.9 511 758 59.0 65.0 68.5 72.5 68.5 72.5
37.0
Lo 5250 5789 1.1 1.3 1.4 1.8 482 730 58.5
64.5 68.0 72.0 68.0 72.0
