10
SQT0455
Specifications
Specifications are subject to change without notice.
INTERCHANGEABLE LENS FOR DIGITAL CAMERA
“LUMIX G 14 mm/F2.5 Ⅱ ASPH.”
Focal length f=14 mm
(35 mm film camera equivalent: 28 mm)
Aperture type 7 diaphragm blades/circular aperture diaphragm
Maximum aperture F2.5
Minimum aperture value F22
Lens construction 6 elements in 5 groups (3 aspherical lenses)
In focus distance 0.18 m
to ¶ (from the focus distance reference line)
Maximum image magnification 0.1k (35 mm film camera equivalent: 0.2k)
Optical image stabiliser Not available
Mount “Micro Four Thirds Mount”
Angle of view 75x
Filter diameter 46 mm
Max. diameter Approx. 55.5 mm
Overall length Approx. 20.5 mm
(from the tip of the lens to the base side of the lens mount)
Mass Approx. 55 g
SQT0455_E.book 10 ページ ２０１４年８月１８日 月曜日 午後４時２９分
