Panasonic KX-TGDA20 - Installation and Accessories; Connections and Wall Mounting

Accessory information
Supplied accessories
Accessory item/Order number Quantity
Charger/PNLC1056ZN 1
Rechargeable batteries/HHR-4DPA 2
Handset cover
*1
/
PNYNTGDA20NR
1
Belt clip/PNKE1054Z4 1
*1 The handset cover comes attached to the handset.
No
te:
R Please read the base unit’s operating instructions for additional/replacement
accessories.
Setting up
Connections/Wall mounting
Connect the AC adaptor to the power outlet.
Drive the screws
1
(not supplied) into the wall, if necessary.
2
27.2 mm (1 1/16 inches)
1
2
1
2
Note:
R T
h
e AC adaptor must remain connected at all times. (It is normal for the adaptor
to feel warm during use.)
R Make sure that the wall and the fixing method are strong enough to support the
weight of the unit.
2
For assistance, please visit http://www.panasonic.com/help
Installation
