Panasonic Lumix DC-GH5EFK Owner's Manual

105
4. Focus, Brightness (Exposure) and Color tone Settings
Compensating the Exposure
Applicable modes:
Use this function when you cannot achieve appropriate exposure due to the difference in
brightness between the subject and the background.
1
Press [ ].
2
Rotate the rear dial to compensate the
exposure.
A Exposure Bracket
B Exposure Compensation
C [Flash Adjust.]
• You can perform the operations below while the
exposure compensation screen is displayed.
• You can switch the functions between the rear dial and the front dial by pressing [DISP.].
3
Press [ ] to set.
• You can also press the shutter button halfway to set.
Compensates the exposure
Adjusts the flash output (P158)
3/4 Sets the exposure bracket (P140)
Underexposed Properly exposed Overexposed
Compensate the exposure
towards positive.
Compensate the exposure
towards negative.
+3+3+1+1 +2+2 +3+3
-
5
-
5
-
4
-
4
-
3
-
3
-
2
-
2
-
1
-
100
+5+5+4+4
+1
+1
0
OFF
OFF

Panasonic Lumix DC-GH5EFK Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	20.3 MP
Megapixels	20.3 MP
Image Processor	Venus Engine
Lens Mount	Micro Four Thirds
Autofocus Points	225
Wi-Fi	Yes
Bluetooth	Yes
Memory Card Slots	2
Dimensions	138.5 x 98.1 x 87.4 mm
Sensor Size	17.3 x 13 mm
Image Sensor Format	Four Thirds
ISO Range	100-25600
Shutter Speed	1/8000 sec - 60 sec
Continuous Shooting	12 fps
Video Resolution	4K (3840 x 2160)
Video Recording	C4K/4K/1080p
Image Stabilization	In-body 5-axis stabilization
Stabilization	5-axis in-body image stabilization
Viewfinder Type	Electronic
Viewfinder	3.68 million-dot OLED
Screen Type	Touchscreen
LCD Screen	3.2-inch Free-Angle Touch LCD
Autofocus System	Contrast-detect AF
Connectivity	Wi-Fi, Bluetooth
Ports	HDMI
Storage Media	SD/SDHC/SDXC
Battery Life	410 shots
Weight	725 g
ISO Sensitivity	Auto, 200-25600 (expandable to 100-25600)
Screen Size	3.2 inches
