Panasonic Lumix DC-GH5EFK Basic Operating Instructions

Recording
32
DVQX1072 (ENG)
Specifying the AF area position
• When [Focus Switching for Vert / Hor] in the [Custom] ([Focus / Release Shutter]) menu is set,
the last specified positions of the AF area (when [
Ø] or [ ] is set) and the MF Assist display
are stored separately for the camera’s horizontal and vertical orientations (two vertical
orientations, left and right, are available).
Applicable modes:
∫ When selecting [š], [ ], [Ø]
1 Press [ ].
2 Select [š], [ ] or [Ø] and press 4.
3 Change the position and size of the AF area.
4 Press [MENU/SET] to set.
• AF area with the same function as [Ø] is displayed in the touched position, when the [š]
is selected.
Setting of the AF area is cleared when [MENU/SET] is pressed or [ ] is touched.
([225-Area])
Up to 225 AF areas can be focused.
This is effective when a subject is not in the centre of the screen.
, etc.
([Custom Multi])
From among 225 AF areas, you can freely set the optimum shape of the
AF area for the subject.
([1-Area])
The camera focuses on the subject in the AF area on the screen.
([Pinpoint])
You can achieve a more precise focus on a point that is smaller than
[Ø].
If you press the shutter button halfway, the screen that lets you check
the focus will be enlarged.
Specifying the AF area position on the setting screen
Button
operation
Touch
operation
Description of operation
3/4/2/1 Touching Moves the position
//
Pinching out/in Changes the size
[DISP.] [Reset]
First time: The position is
reset to the centre
Second time: The size is
reset to the default
DC-GH5BodyGN-DVQX1072_eng.book 32 ページ ２０１７年２月１３日 月曜日 午前１１時４５分

Panasonic Lumix DC-GH5EFK Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	20.3 MP
Megapixels	20.3 MP
Image Processor	Venus Engine
Lens Mount	Micro Four Thirds
Autofocus Points	225
Wi-Fi	Yes
Bluetooth	Yes
Memory Card Slots	2
Dimensions	138.5 x 98.1 x 87.4 mm
Sensor Size	17.3 x 13 mm
Image Sensor Format	Four Thirds
ISO Range	100-25600
Shutter Speed	1/8000 sec - 60 sec
Continuous Shooting	12 fps
Video Resolution	4K (3840 x 2160)
Video Recording	C4K/4K/1080p
Image Stabilization	In-body 5-axis stabilization
Stabilization	5-axis in-body image stabilization
Viewfinder Type	Electronic
Viewfinder	3.68 million-dot OLED
Screen Type	Touchscreen
LCD Screen	3.2-inch Free-Angle Touch LCD
Autofocus System	Contrast-detect AF
Connectivity	Wi-Fi, Bluetooth
Ports	HDMI
Storage Media	SD/SDHC/SDXC
Battery Life	410 shots
Weight	725 g
ISO Sensitivity	Auto, 200-25600 (expandable to 100-25600)
Screen Size	3.2 inches
