Panasonic LUMIX DC-GX9K Basic Operating Instructions

13
DVQX1391 (ENG)
Preparations/Basics
■
Lens
H-FS12032
1 3
5 6
2 4
H-FS35100
1 7
5 6
3 2 4
H-FS12060
1 3
5 6
2 4 7
9
H-FS1442A
1 7
5 6
3 2 4
1 Lens surface
2
Tele
3
Zoom ring
4
Wide
5
Contact point
6
Lens fitting mark (→19)
7
Focus ring (→33)
8
[O.I.S.] switch (→46)
9
Lens mount rubber
H-FS14140
1
5 6
2 7 3 4 8
■
Removing the Hot Shoe Cover
The camera comes with a hot shoe cover attached to
the hot shoe.
Remove the hot shoe cover by pulling it in the
direction indicated by arrow
while pressing it in
the direction indicated by arrow
.
