- 7 -
Before Use
8 Camera ON/OFF switch (P18)
9 Zoom lever (P43)
10 Speaker (P36)
11 Microphone
12 Shutter button (P21, 24, 30)
13 [E.ZOOM] button (P45)
14 Tripod receptacle
15 Card/Battery door (P13, 14)
16 DC coupler cover (P14)
•
When using an AC adaptor, ensure that
the Panasonic DC coupler (optional) and
AC adaptor (optional) are used. For
connection details, refer to P14.
9
10 11 12 13
8
ヮユヮヰンヺチヤモンュチバ
ャモヵヵユンヺ
15
16
14
