- 7 -
Before Use
Names of the Components
1Flash (P49)
2Lens (P140)
3 Self-timer indicator (P56)
AF assist lamp (P97)
4 LCD monitor (P47, 136)
5 Status indicator (P15, 26, 32)
6 [MENU/SET] button (P18)
7 [DISPLAY] button (P47)
8 [Q.MENU] (P23)/Delete (P45) button
9 [REC]/[PLAYBACK] selector switch
(P20)
10 Cursor buttons
A: 3/Exposure compensation (P57)/
Auto bracket (P58)/White balance
fine adjustment (P89)
B: 4/Macro mode (P54)
AF Tracking (P35, 92)
C: 2/Self-timer button (P56)
D: 1/Flash setting button (P49)
In these operating instructions, the cursor buttons are described as shown in the
figure below or described with 3/4/2/1.
e.g.: When you press the 4 (down) button
or Press 4
123
