VQT3Q80 (ENG)
14
Align the lens fitting marks B (red marks) and then rotate the lens in the
direction of the arrow until it clicks.
• Do not press the lens release button A when you attach a lens.
• Do not try to attach the lens when holding it at an angle to the camera body as the lens mount
may get scratched.
• Be sure to remove the lens cap when recording.
Note
•
Do not insert your fingers into the mount when the lens and body cap
are removed from the camera body.
• To prevent dust or debris from adhering to internal parts of the
camera body, fit the body cap or a lens to the mount on the camera
body.
• To prevent scratching of the contact points, fit the lens rear cap to the
lens when it is unattached or fit the lens to the camera body.
• It is recommended to attach the lens cap or attach the MC Protector
(optional) to protect the lens surface when carrying.
Attaching the lens
Preparations: Remove the rear lens cap from the lens.
•
If the body cap is fitted to the camera, remove it.
DMC-GF3C&GF3K&GF3PC-VQT3Q80_eng.book 14 ページ ２０１１年５月３０日 月曜日 午後１時１５分
