Panasonic Lumix DMC-GF7 Operating Instructions

123
4. Picture Quality and Colour Tone Settings
Adjusting the White Balance
Applicable modes:
In sunlight, under incandescent lights or in other such conditions where the colour of white
takes on a reddish or bluish tinge, this item adjusts to the colour of white which is closest
to what is seen by the eye in accordance with the light source.
1
Press 1 ( ).
2
Select the White Balance by rotating the
control dial.
[AWB] Automatic adjustment
[V] When taking pictures outdoors under a clear sky
[Ð] When taking pictures outdoors under a cloudy sky
[î] When taking pictures outdoors in the shade
[Ñ] When taking pictures under incandescent lights
[]
¢
When taking pictures with the flash only
[]/[]
Set the White Balance value. Use to match the
condition when taking photographs.
1 Press
3
2 Aim the camera at a sheet of white paper
etc. so that the frame in the centre is filled by
the white object only and then press [MENU/SET].
•
This will set the White Balance and return you to the recording
screen.
• The same operation can be performed by pressing the shutter button.
• White Balance may not be set when the subject is too bright or too
dark. Set the White Balance again after adjusting to appropriate
brightness.
WB
WBWBWB
WBWBWBWBWBWBWB
AWB
AWB
1
2

Panasonic Lumix DMC-GF7 Specifications

General

Megapixel	16 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	16.84 MP
Image sensor size	- \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4592 x 3448 pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Lens
Still image resolution(s)	4592x3448 3232x2424 2272x1704 1824x1368 4592x3064 3232x2160 2272x1520 1824x1216 4592x2584 3840x2160 1920x1080 1824x1024 3424x3424 2416x2416 1712x1712
Power source type	Battery
Battery voltage	7.2 V
Battery life (max)	680 h
Battery life (CIPA standard)	230 shots
Filter size	37 mm
Digital zoom	4 x
Optical zoom	- x
Focal length range	12 - 32 mm
Lens mount interface	Micro Four Thirds (MFT)
Maximum aperture number	22
Minimum aperture number	3.5
Number of diaphragm blades	7
Lens structure (elements/groups)	8/7
Maximum focal length (35mm film equiv)	64 mm
Minimum focal length (35mm film equiv)	24 mm
Product color	White
Focus adjustment	Auto
Auto focusing (AF) modes	Centre weighted Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance	0.2 m
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/16000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	0.02 s
Flash guide number	5.6 m
Flash range (wide)	- m
Flash exposure correction	±2EV (1/3 EV step)
Cables included	USB
Bundled software	PHOTOfunSTUDIO 9.6 PE SILKYPIX Developer Studio 4.2 SE LoiLoScope
Video formats supported	AVCHD, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	640x480@25fps, 640x480@30fps, 1280x720@25fps, 1280x720@30fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps
Audio system	stereo
Audio formats supported	AAC
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Second display	No
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1040000 pixels
USB version	2.0
HDMI connector type	Micro
Bluetooth	-
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Children, Night, Night portrait, Panorama, Portrait
Image editing	Crop, Resizing, Rotating
Photo effects	Black&White, Skin tones, Vivid
White balance	Auto, Cloudy, Daylight, Flash, Shade
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Languages support	Multi
Playback zoom (max)	16 x

Weight and Dimensions

Depth	33.3 mm
Width	106.5 mm
Height	64.6 mm
Weight	236 g
Lens weight	70 g
Lens diameter	55.5 mm
Weight (including battery)	336 g
