Panasonic Lumix DMC-ZR3 - Names of the Components

VQT2L93 (ENG)
10
Names of the Components
1Flash
2Lens
3 Self-timer indicator
AF assist lamp
4 LCD monitor
5 [MENU/SET] button
6 [DISPLAY] button
7 [Q.MENU]/Delete button
8 [REC]/[PLAYBACK] selector switch
9 Motion picture button
10 Cursor buttons
A
: 3/Exposure compensation/Auto
Bracket/White Balance fine adjustment
B
: 4/Macro Mode
AF Tracking
C
: 2/Self-timer button
D
: 1/Flash setting button
In these operating instructions, the cursor buttons are described as shown
in the figure below or described with 3/4/2/1.
e.g.: When you press the 4 (down) button
or Press 4
123
9
4
8
675
10
