Panasonic LUMIX DMC-ZS100

16
Preparations
SQT1166 (ENG)
1 Shutter button (→22)
2
Zoom lever (→21)
3
Motion picture button (→37)
4
Mode dial (→23)
5
ZS100
Camera [ON/OFF] switch
ZS60
Camera [ON/OFF] button
6
ZS100
Rear dial (→26)
7
Self-timer indicator/AF assist lamp
8
Flash
9
Viewfinder (→25, 52)
10
Diopter adjustment dial
11
Eye sensor (→25)
12
Stereo microphone
13
Strap eyelet
• To prevent dropping, be sure to
attach the supplied strap and fit it to
your wrist.
14
ZS60
Speaker
15
Control ring (→26)
16
Lens barrel
17
Lens
18
[LVF] button (→25)/[Fn4] button
19
ZS100
Flash open lever
20
ZS100
[AF/AE LOCK] button
• You can take pictures by locking the
focus and/or exposure.
21
Charging lamp (→18)/
Wi-Fi
®
connection lamp
22
[
] ([Post Focus]) button (→33)/
[Fn2] button
23
ZS60
Control dial (→26)
24
[Q.MENU/
] (Cancel) button/
[
] (Delete) button (→41)/
[Fn3] button
• You can easily call some of the menu
items and set them during recording.
25
[
] (4K photo mode) button (→30)/
[Fn1] button
26
[
] (Playback) button (→41)
27
Cursor button (→24)
28
[MENU/SET] button
29
[DISP.] button
• Use this to change display.
30
[HDMI] socket
31
[CHARGE] socket (→18)
32
Touch screen (→27)/monitor (→52)
33
ZS100
Speaker
34
Tripod mount
• Do not attach this unit to tripods that
have screws with a length of 5.5 mm
(0.22 inch) or more. Doing so may
damage this unit or the unit may not be
secured properly on the tripod.
35
DC coupler cover (→67)
36
Release lever (→17)
37
Card/Battery door (→17)
●
Always use the supplied AC adaptor
or a genuine Panasonic AC adaptor
(DMW-AC10PP: optional). (→67)
When using an AC adaptor (DMW-
AC10PP: optional), ensure that
the Panasonic DC coupler (DMW-
DCC11: optional) and AC adaptor
(DMW-AC10PP: optional) are used.
●
[Fn5] to [Fn9] (→24) are touch icons.
They are displayed by touching the
[
] tab on the recording screen.
