Panasonic Lumix DMC-ZS15 Basic Owner's Manual

(ENG) VQT4B28 5
■
Cautions for Use
• Do not use any other USB connection cables except the supplied one.
• Always use a genuine Panasonic HDMI mini cable
(RP-CDHM15, RP-CDHM30: optional).
Part numbers: RP-CDHM15 (1.5 m) (4.9 feet), RP-CDHM30 (3.0 m) (9.8 feet)
• Always use a genuine Panasonic AV cable (DMW-AVC1: optional).
Keep this unit as far away as possible from electromagnetic equipment (such
as microwave ovens, TVs, video games etc.).
• If you use this unit on top of or near a TV, the pictures and/or sound on this unit
may be disrupted by electromagnetic wave radiation.
• Do not use this unit near cell phones because doing so may result in noise
adversely affecting the pictures and/or sound.
• Recorded data may be damaged, or pictures may be distorted, by strong
magnetic fields created by speakers or large motors.
• Electromagnetic wave radiation generated by microprocessors may adversely
affect this unit, disturbing the pictures and/or sound.
• If this unit is adversely affected by electromagnetic equipment and stops
functioning properly, turn this unit off and remove the battery or disconnect AC
adaptor (supplied). Then reinsert the battery or reconnect AC adaptor and turn
this unit on.
Do not use this unit near radio transmitters or high-voltage lines.
• If you record near radio transmitters or high-voltage lines, the recorded pictures
and/or sound may be adversely affected.
For information about the software used for this product, press [MENU/SET] and
select [Setup] to display [Version Disp.] before pressing [MENU/SET] again.
This product is licensed under the AVC patent portfolio license for the personal
and non-commercial use of a consumer to (i) encode video in compliance with
the AVC Standard (“AVC Video”) and/or (ii) decode AVC Video that was encoded
by a consumer engaged in a personal and non-commercial activity and/or was
obtained from a video provider licensed to provide AVC Video. No license is
granted or shall be implied for any other use. Additional information may be
obtained from MPEG LA, LLC.
See http://www.mpegla.com.

Panasonic Lumix DMC-ZS15 Specifications

General

Megapixel	12.1 MP
Camera type	Compact camera
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	12.8 MP
Image sensor size	1/2.3 \
Image formats supported	JPEG XR
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4000 x 3000 pixels
Still image resolution(s)	[1:1] 2992x2992, 2448x2448, 1920x1920, 1536x1536, 480x480\\r [4:3] 4000x3000, 3264x2448, 2560x1920, 2048X1536, 1600x1200, 640x480\\r [3:2] 4000x2672, 3264x2176, 2560x1712, 2048x1360, 640x424\\r [16:9] 4000x2248, 3264x1840, 2560x1440, 1920x1080, 640x360
Digital zoom	4 x
Optical zoom	16 x
Extra/Smart zoom	19.6 x
Focal length range	4.3 - 68.8 mm
Minimum aperture number	-
Lens structure (elements/groups)	12/10
Maximum focal length (35mm film equiv)	384 mm
Minimum focal length (35mm film equiv)	24 mm
Focus adjustment	Auto/Manual
Normal focusing range	0.5 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Tracking Auto Focus
Macro focusing range (tele)	1 - ∞ m
Macro focusing range (wide)	0.03 - ∞ m
Normal focusing range (tele)	2 - ∞ m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 1600, 3200, 6400
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 1EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	15 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 3.5 m
Flash range (wide)	0.6 - 6.4 m
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC
Audio system	Mono
Internal memory	70 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
USB version	2.0
HDMI connector type	Mini
Product color	Black
Scene modes	Children, Cuisine, Night, Night landscape, Night portrait, Panorama, Pet, Portrait, Sports, Sunset, Underwater, Landscape (scenery)
Image editing	Crop, Resizing
Photo effects	Black&White, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Incandescent, Shade
Camera playback	Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3
On Screen Display (OSD) languages	ENG, ESP
Battery voltage	3.6 V
Battery capacity	895 mAh
Battery life (CIPA standard)	260 shots
Cables included	USB
Bluetooth	No

Weight and Dimensions

Depth	33.4 mm
Width	104.9 mm
Height	57.6 mm
Weight	185 g
Weight (including battery)	208 g
